@rcorless

Maybe of interest: Maple can now analytically verify that this is a solution.

I did not know that there is an explict solution appart from a series approach. Does the "magnificent book" give details how that explicit solution can be derived? I would like to understand if and how such a derivation can be reprocuded with Maple.

Reply_HarmonicOscillator-1.mw

@sursumCorda

The effective use of the empty symbol surprised me. I thought `` makes expression "inert" to simplification. Now a see the opposite: convert/D fully evaluates

Do you have any explanations (or documentation beyond help(emptysymbol)) for this?

@Carl Love

Retrospectively I can see it now.

@acer

Thank you for taking the time to describe this detail of returning an unevaluated eval call in an easy to understand way.

I did assume that the inert functions where returned unevaluated by convert(…, D).

I have attached all possible combinations of defining IC/BCs in common math output notation (i.e., understandable also for non-Maple users) with relevant commands. Maybe it's better practice to define an IC/BC with eval(Diff…) instead of Eval(diff…), which makes convert(...,D) work without eval.  Let's see.

By the way, your foo example is a good addition to eval, Eval, D and more. Evaluating something at a point that is not returned  in a  fully evaluated representation but can (only?) be displayed with eval(...,1) which outputs the internal representation touches essential aspects of Maple worth understanding.

Download Convert_inert_IC_to_D_notation_in_various_combinations.mw

@mmcdara

Better rendering.

Your code does not return "domains" in the same way with Maple 2023. I cannot make sense of Maples output in both cases.

Replacing < by = combined with allsolutions gives a reasonable expression for the subdomain ranges.

Domains-2_M2023.mw

Yours:

With 2023 nothing is returned for f(1)

@sursumCorda

Finally I found something which is, combined with your DETools commands, an acceptable way.

Thanks again

Download 236511-How-To-Integrate-This-Ode-And-How-To-1_reply_2.mws

I think you meant: ...the term I * Int(f(x), x).

This one works:

I*Int(f(x), x) = something - 2*I*Int(f(x), x);
isolate(%,Int(f(x), x))

@Rouben Rostamian

I understand that there is no such solution. I am looking more for Maple techniques that provide “elegant” solutions. What I could achieve did not match my expectations (especially my failed substitution attempts). In this respect you have given a good example for the first integration step: Exclusive use of equations and high-level commands.

I had the hope that there could be a forward integration step (using only de and bc) coming to the same result as with your solution (maybe with a clever combination of DETools commands or the Physic package).

(The backward step you have taken in combination with a dsolve command that preserves the integration variable and removes the second integration constant is something I have to think about. This could become handy on other occasions.)

I have spared out the second integrations step which is of topic of my questions Q1 and Q2 and has to be approached differently for the pendulum and the elastic beam since the first one is an initial value problem whereas the other is a boundary value problem. I hope I can find a satisfying solution myself.

Thank you for providing the best way for Q1 and Q2 in one go so far!

@Rouben Rostamian

As I haven't found a solution to this ODE using top-level Maple commands, my objective is to replicate the steps outlined in a publication that solves this ODE manually. I have outlined my random path of experiments in the attached reply.

Your way is smart since it avoids manual substitution of a boundary condition at all and prevents the dead ends one is confronted with when a solution returned from Mapel can’t be differentiated with respect to the independent variable (like Student:-ODEs:-ODESteps({bc, de})). So, thumbs up for that, but how could I have figured that out myself? Is this really the "best" way in the sense of good ode solving practise to avoid manual or "terrible" ways?

I have to admit this ode and its sibling has attracked my attention beyond practical need. First of all, there is everyday physics behind everyone knows: bending of elastic beams and the pendulum.  Secondly, as I have realized in the meantime, the second integration step can’t be formulated in terms of boundary conditions or initial conditions Maple accepts.

Maplesoft has done quite some efforts of providing education material and packages. It's good and I myself have learned allot. I can’t judge if these odes are of value form an educational standpoint. However, I wanted to highlight some problems (in particular defineing and handling ICs and BCs) and related questions a student may encounter. This is kind of a secondary objective.

Download mw-1_reply.mw

@sursumCorda
I think your way to Q1 with 2 out of more than 130 (!) DETools commands is not terrible. The missing bit for me when I got this Error

was that I can potenially make an ODE exact by multiplying it with an integration factor. If this is the only way, Student:-ODEs:-Integrate could have added a hint.
Also: Strange that the examples of ?DEtools,firint sometime come with _C1 and c__1.

Even if "terrible": Why does this comes as an exponent?Edit: fount the explanation

Let's see if there are less terrible ways.

Thank you

@sursumCorda

I do not understand. This is how it looks like when I execute your attachment with Maple 2023. Please consider that I have only basic knowledge about ODEs and Maples possibilites. With some additional explanation, I could better understand your answer.

Download 236511-How-To-Integrate-This-Ode-And-How-To-1_reply.mws

@acer This will be an easy fix. Thank you !

Applyrule should have worked on equations (since equations are expressions in Maple terms, see ?equation)

but it does not

a = b;
applyrule(b = c, %);
map2(applyrule, b = c, `%%`);

I have send a software change request that either the helppage is updated or applyrule.

@nm

You pretty much described what I had in mind. If the LOOP runs in Maple one could think of setting a timer with a bit of extra margin that on average more Mapleserver.exe are terminated than stated. This would prevent a system overflow.

I have managed to start a maple server with the command below and load a *.mw file.

system("\"C:\\Program Files\\Maple 2023\\bin.X86_64_WINDOWS\\maplew.exe\" -a \" C:\\Users\\CR\\Desktop\\kernellost.mw \"");

Similarily esc works, see help(esc).

Also *.bat file can be excecuted with the same windows commands

Using -e instead of -a should execute the argument that follows the -e. I have tried to put a read statement around the file but have to stop here for today.

read(\" C:\\Users\\CR\\Desktop\\kernellost.mw \"")

Update:

On MaplePrimes I found more on read

https://www.mapleprimes.com/questions/202016-Batch-Process-Worksheets-And-Save-As-PDF

and the possibility to run skripts *.mpl

https://www.mapleprimes.com/questions/223885-Batch-File-For-Window-Run-Maple-Input-File-

If you could programatically transfrom your problems into a skript files (one per problem) you should be able to either execute them one by one from Maple in a LOOP or run a batch job on a system level.

Also interesting in this contaxt:

https://www.mapleprimes.com/maplesoftblog/209538-Can-I-Programmatically-Modify-Batch

Could you share the CAD component using ?
