These are answers submitted by dharr

restart

with(PDEtools)

_local(gamma)

undeclare(prime)

`There is no more prime differentiation variable; all derivatives will be displayed as indexed functions`

declare(V(xi))

V(xi)*`will now be displayed as`*V

Eq 3.3 doi: 10.3934/math.2024424

Fode := k*theta^2*V(xi)-rho*V(xi)+a[1]*V(xi)^2-b[1]*rho*(diff(diff(V(xi), xi), xi))+V(xi)

k*theta^2*V(xi)-rho*V(xi)+a[1]*V(xi)^2-b[1]*rho*(diff(diff(V(xi), xi), xi))+V(xi)

Eq 3.16

S := V(xi) = sum((alpha[i]+beta[i]*(diff(G(xi), xi))^i)/G(xi)^i, i = 0 .. 2)

V(xi) = alpha[0]+beta[0]+(alpha[1]+beta[1]*(diff(G(xi), xi)))/G(xi)+(alpha[2]+beta[2]*(diff(G(xi), xi))^2)/G(xi)^2

Eq. 2.8

Aode := (diff(G(xi), xi))^2 = (G(xi)^2-sigma)*ln(A)^2

(diff(G(xi), xi))^2 = (G(xi)^2-sigma)*ln(A)^2

Eq. 2.9, n=2,3,4

Aode2 := (diff(Aode, xi))/(2*(diff(G(xi), xi))); Aode3 := diff(Aode2, xi); diff(Aode3, xi); Aode4 := lhs(%) = eval(rhs(%), Aode2)

diff(diff(G(xi), xi), xi) = G(xi)*ln(A)^2

diff(diff(diff(G(xi), xi), xi), xi) = (diff(G(xi), xi))*ln(A)^2

diff(diff(diff(diff(G(xi), xi), xi), xi), xi) = (diff(diff(G(xi), xi), xi))*ln(A)^2

diff(diff(diff(diff(G(xi), xi), xi), xi), xi) = G(xi)*ln(A)^4

Eq 2.10

solution := G(xi) = kappa*ln(A)*A^xi+sigma/(4*kappa*ln(A)*A^xi)

G(xi) = kappa*ln(A)*A^xi+(1/4)*sigma/(kappa*ln(A)*A^xi)

odetest(solution, Aode)

0

E1 := eval(Fode, S); indets(E1)

{k, rho, theta, xi, a[1], alpha[0], alpha[1], alpha[2], b[1], beta[0], beta[1], beta[2], G(xi), diff(G(xi), xi), diff(diff(G(xi), xi), xi), diff(diff(diff(G(xi), xi), xi), xi)}

E2 := dsubs(Aode3, E1); indets(E2)

{A, k, rho, theta, xi, a[1], alpha[0], alpha[1], alpha[2], b[1], beta[0], beta[1], beta[2], G(xi), diff(G(xi), xi), diff(diff(G(xi), xi), xi), ln(A)}

E3 := dsubs(Aode2, E2); indets(E3)

{A, k, rho, theta, xi, a[1], alpha[0], alpha[1], alpha[2], b[1], beta[0], beta[1], beta[2], G(xi), diff(G(xi), xi), ln(A)}

We haven't used Aode yet, so we don't have any sigmas

E4 := dsubs(Aode, E3); indets(E4)

E5 := dsubs(diff(G(xi), xi) = dG, E4); indets(%)

{A, dG, k, rho, sigma, theta, xi, a[1], alpha[0], alpha[1], alpha[2], b[1], beta[0], beta[1], beta[2], G(xi), ln(A)}

Doesn't seem to be a polynomial in dG/G^2 as claimed:

C := collect(E5, {dG, G(xi)}, distributed)

(-6*rho*b[1]*beta[2]+a[1]*beta[2]^2)*dG^4/G(xi)^4+(-2*rho*b[1]*beta[1]+2*a[1]*beta[1]*beta[2])*dG^3/G(xi)^3+(2*ln(A)^2*rho*b[1]*beta[1]+k*theta^2*beta[1]+2*a[1]*alpha[0]*beta[1]+2*a[1]*beta[0]*beta[1]-rho*beta[1]+beta[1])*dG/G(xi)+k*theta^2*alpha[0]+k*theta^2*beta[0]+2*a[1]*alpha[0]*beta[0]+ln(A)^2*a[1]*beta[1]^2-ln(A)^2*rho*beta[2]+2*ln(A)^2*a[1]*alpha[0]*beta[2]+2*ln(A)^2*a[1]*beta[0]*beta[2]+alpha[0]+beta[0]+6*ln(A)^4*rho*b[1]*beta[2]+ln(A)^2*k*theta^2*beta[2]+a[1]*alpha[0]^2+a[1]*beta[0]^2-rho*alpha[0]-rho*beta[0]+ln(A)^2*beta[2]+(-ln(A)^2*rho*alpha[1]*b[1]+2*ln(A)^2*a[1]*alpha[1]*beta[2]+k*theta^2*alpha[1]+2*a[1]*alpha[0]*alpha[1]+2*a[1]*alpha[1]*beta[0]-rho*alpha[1]+alpha[1])/G(xi)+(-8*ln(A)^4*rho*sigma*b[1]*beta[2]-ln(A)^2*k*sigma*theta^2*beta[2]-2*ln(A)^2*sigma*a[1]*alpha[0]*beta[2]-2*ln(A)^2*sigma*a[1]*beta[0]*beta[2]-ln(A)^2*sigma*a[1]*beta[1]^2+ln(A)^2*rho*sigma*beta[2]-4*ln(A)^2*rho*alpha[2]*b[1]+2*ln(A)^2*a[1]*alpha[2]*beta[2]-ln(A)^2*sigma*beta[2]+k*theta^2*alpha[2]+2*a[1]*alpha[0]*alpha[2]+a[1]*alpha[1]^2+2*a[1]*alpha[2]*beta[0]-rho*alpha[2]+alpha[2])/G(xi)^2+(2*ln(A)^2*rho*sigma*alpha[1]*b[1]-2*ln(A)^2*sigma*a[1]*alpha[1]*beta[2]+2*a[1]*alpha[1]*alpha[2])/G(xi)^3+(6*ln(A)^2*rho*sigma*alpha[2]*b[1]-2*ln(A)^2*sigma*a[1]*alpha[2]*beta[2]+a[1]*alpha[2]^2)/G(xi)^4+2*a[1]*alpha[2]*beta[1]*dG/G(xi)^3+2*a[1]*alpha[1]*beta[1]*dG/G(xi)^2

We get 10, not 8 equations this way.

eqs := {coeffs(C, {dG, G(xi)}, 'monomials')}; nops(%)

{2*a[1]*alpha[1]*beta[1], 2*a[1]*alpha[2]*beta[1], 2*ln(A)^2*rho*sigma*alpha[1]*b[1]-2*ln(A)^2*sigma*a[1]*alpha[1]*beta[2]+2*a[1]*alpha[1]*alpha[2], 6*ln(A)^2*rho*sigma*alpha[2]*b[1]-2*ln(A)^2*sigma*a[1]*alpha[2]*beta[2]+a[1]*alpha[2]^2, 2*ln(A)^2*rho*b[1]*beta[1]+k*theta^2*beta[1]+2*a[1]*alpha[0]*beta[1]+2*a[1]*beta[0]*beta[1]-rho*beta[1]+beta[1], -ln(A)^2*rho*alpha[1]*b[1]+2*ln(A)^2*a[1]*alpha[1]*beta[2]+k*theta^2*alpha[1]+2*a[1]*alpha[0]*alpha[1]+2*a[1]*alpha[1]*beta[0]-rho*alpha[1]+alpha[1], -8*ln(A)^4*rho*sigma*b[1]*beta[2]-ln(A)^2*k*sigma*theta^2*beta[2]-2*ln(A)^2*sigma*a[1]*alpha[0]*beta[2]-2*ln(A)^2*sigma*a[1]*beta[0]*beta[2]-ln(A)^2*sigma*a[1]*beta[1]^2+ln(A)^2*rho*sigma*beta[2]-4*ln(A)^2*rho*alpha[2]*b[1]+2*ln(A)^2*a[1]*alpha[2]*beta[2]-ln(A)^2*sigma*beta[2]+k*theta^2*alpha[2]+2*a[1]*alpha[0]*alpha[2]+a[1]*alpha[1]^2+2*a[1]*alpha[2]*beta[0]-rho*alpha[2]+alpha[2], 6*ln(A)^4*rho*b[1]*beta[2]+ln(A)^2*k*theta^2*beta[2]+2*ln(A)^2*a[1]*alpha[0]*beta[2]+2*ln(A)^2*a[1]*beta[0]*beta[2]+ln(A)^2*a[1]*beta[1]^2-ln(A)^2*rho*beta[2]+k*theta^2*alpha[0]+k*theta^2*beta[0]+ln(A)^2*beta[2]+a[1]*alpha[0]^2+2*a[1]*alpha[0]*beta[0]+a[1]*beta[0]^2-rho*alpha[0]-rho*beta[0]+alpha[0]+beta[0], -6*rho*b[1]*beta[2]+a[1]*beta[2]^2, -2*rho*b[1]*beta[1]+2*a[1]*beta[1]*beta[2]}

10

ans := sort([solve(eqs, {rho, alpha[0], alpha[1], alpha[2], beta[0], beta[1], beta[2]})])

[{rho = rho, alpha[0] = -beta[0], alpha[1] = 0, alpha[2] = 0, beta[0] = beta[0], beta[1] = 0, beta[2] = 0}, {rho = (k*theta^2+1)/(4*ln(A)^2*b[1]+1), alpha[0] = -beta[0], alpha[1] = 0, alpha[2] = -6*ln(A)^2*(k*theta^2+1)*sigma*b[1]/((4*ln(A)^2*b[1]+1)*a[1]), beta[0] = beta[0], beta[1] = 0, beta[2] = 0}, {rho = (k*theta^2+1)/(4*ln(A)^2*b[1]+1), alpha[0] = -(6*k*theta^2*ln(A)^2*b[1]+4*ln(A)^2*a[1]*b[1]*beta[0]+6*ln(A)^2*b[1]+a[1]*beta[0])/((4*ln(A)^2*b[1]+1)*a[1]), alpha[1] = 0, alpha[2] = 0, beta[0] = beta[0], beta[1] = 0, beta[2] = 6*(k*theta^2+1)*b[1]/((4*ln(A)^2*b[1]+1)*a[1])}, {rho = -(k*theta^2+1)/(4*ln(A)^2*b[1]-1), alpha[0] = (2*k*theta^2*ln(A)^2*b[1]-4*ln(A)^2*a[1]*b[1]*beta[0]+2*ln(A)^2*b[1]+a[1]*beta[0])/((4*ln(A)^2*b[1]-1)*a[1]), alpha[1] = 0, alpha[2] = 0, beta[0] = beta[0], beta[1] = 0, beta[2] = -6*(k*theta^2+1)*b[1]/((4*ln(A)^2*b[1]-1)*a[1])}, {rho = -(k*theta^2+1)/(4*ln(A)^2*b[1]-1), alpha[0] = -(4*k*theta^2*ln(A)^2*b[1]+4*ln(A)^2*a[1]*b[1]*beta[0]+4*ln(A)^2*b[1]-a[1]*beta[0])/((4*ln(A)^2*b[1]-1)*a[1]), alpha[1] = 0, alpha[2] = 6*ln(A)^2*(k*theta^2+1)*sigma*b[1]/((4*ln(A)^2*b[1]-1)*a[1]), beta[0] = beta[0], beta[1] = 0, beta[2] = 0}, {rho = (1/6)*a[1]*beta[2]/b[1], alpha[0] = -(1/6)*(6*ln(A)^2*a[1]*b[1]*beta[2]+6*k*theta^2*b[1]+6*a[1]*beta[0]*b[1]-a[1]*beta[2]+6*b[1])/(a[1]*b[1]), alpha[1] = 0, alpha[2] = ln(A)^2*sigma*beta[2], beta[0] = beta[0], beta[1] = 0, beta[2] = beta[2]}, {rho = (1/6)*a[1]*beta[2]/b[1], alpha[0] = -ln(A)^2*beta[2]-beta[0], alpha[1] = 0, alpha[2] = ln(A)^2*sigma*beta[2], beta[0] = beta[0], beta[1] = 0, beta[2] = beta[2]}, {rho = k*theta^2+a[1]*alpha[0]+a[1]*beta[0]+1, alpha[0] = alpha[0], alpha[1] = 0, alpha[2] = 0, beta[0] = beta[0], beta[1] = 0, beta[2] = 0}]

In Eq 3.18 rho is the same. But beta[2] is on the rhs on theirs, but beta[0] here. The denominators are the same. But overall is not the same

ans[3]

{rho = (k*theta^2+1)/(4*ln(A)^2*b[1]+1), alpha[0] = -(6*k*theta^2*ln(A)^2*b[1]+4*ln(A)^2*a[1]*b[1]*beta[0]+6*ln(A)^2*b[1]+a[1]*beta[0])/((4*ln(A)^2*b[1]+1)*a[1]), alpha[1] = 0, alpha[2] = 0, beta[0] = beta[0], beta[1] = 0, beta[2] = 6*(k*theta^2+1)*b[1]/((4*ln(A)^2*b[1]+1)*a[1])}

Eq 3.19. Despite the differences, we get the correct final result.

eval(S, ans[3]); dsubs(Aode, %); sol := simplify(eval(%, solution))

V(xi) = -(6*k*theta^2*ln(A)^2*b[1]+4*ln(A)^2*a[1]*b[1]*beta[0]+6*ln(A)^2*b[1]+a[1]*beta[0])/((4*ln(A)^2*b[1]+1)*a[1])+beta[0]+6*(k*theta^2+1)*b[1]*(diff(G(xi), xi))^2/((4*ln(A)^2*b[1]+1)*a[1]*G(xi)^2)

V(xi) = -6*ln(A)^2*(k*theta^2+1)*sigma*b[1]/((4*ln(A)^2*b[1]+1)*a[1]*G(xi)^2)

V(xi) = -96*ln(A)^4*(k*theta^2+1)*sigma*b[1]*kappa^2*A^(2*xi)/((4*ln(A)^2*b[1]+1)*a[1]*(4*kappa^2*ln(A)^2*A^(2*xi)+sigma)^2)

odetest(sol, eval(Fode, ans[3]))

0

NULL

Download f-p-second.mw

I don't know about (24) - perhaps the paper has a typo in the ode (missing m?).

For (25) and (26), I corrected typos in magenta and the tests are verified.

I don't know about (30) or (31).

There seem to be typos in (40) and (41) but that doesn't solve the problems.

ode-17.mw

You didn't provide explanation about the Weierstraa cases (what is f3?). Maple has the WeierstrassP and WeierstrassPPrime.

The <> constructors are useful here:

ga_zero := <IdentityMatrix(2), ZeroMatrix(2); ZeroMatrix(2), -IdentityMatrix(2) >;

or

ga_zero := <<IdentityMatrix(2) | ZeroMatrix(2)>, <ZeroMatrix(2) | -IdentityMatrix(2)>>;



This method only works since your envelope is always increasing in size. Then you can use the running minimum and maximum values as your envelope.

numsolve-1229.mw

What are we allowed to know here? I don't think you could find dio1 from dio without knowing the form we are seeking. If we do know that form, then we can find the missing numbers using solve as follows:

restart

dio1 := ((x-1)*(y-2)*(z-3))^2+((x-4)*(y-5)*(z-6))^2+((x-7)*(y-8)*(z-9))^2

(x-1)^2*(y-2)^2*(z-3)^2+(x-4)^2*(y-5)^2*(z-6)^2+(x-7)^2*(y-8)^2*(z-9)^2

dio := expand(dio1)

3*x^2*y^2*z^2-36*x^2*y^2*z-30*x^2*y*z^2-24*x*y^2*z^2+126*x^2*y^2+432*x^2*y*z+93*x^2*z^2+360*x*y^2*z+312*x*y*z^2+66*y^2*z^2-1692*x^2*y-1476*x^2*z-1440*x*y^2-5040*x*y*z-1104*x*z^2-1080*y^2*z-948*y*z^2+6120*x^2+21096*x*y+18576*x*z+4554*y^2+16056*y*z+3540*z^2-79848*x-69300*y-61272*z+268452

Suppose we are allowed to know that we want an expression of the following form

dioguess := ((x-a)*(y-b)*(z-c))^2+((x-d)*(y-e)*(z-f))^2+((x-g)*(y-h)*(z-i))^2

(x-a)^2*(y-b)^2*(z-c)^2+(x-d)^2*(y-e)^2*(z-f)^2+(x-g)^2*(y-h)^2*(z-i)^2

Then we require the following to be zero

q := collect(dioguess-dio, {x, y, z}, distributed)

-268452+(a^2+d^2+g^2-66)*y^2*z^2+(-2*a^2*c-2*d^2*f-2*g^2*i+1080)*y^2*z+(-2*a^2*b-2*d^2*e-2*g^2*h+948)*y*z^2+(4*a^2*b*c+4*d^2*e*f+4*g^2*h*i-16056)*y*z+d^2*e^2*f^2+g^2*h^2*i^2+a^2*b^2*c^2+(-2*a*c^2-2*d*f^2-2*g*i^2+1440)*x*y^2+(4*a*b*c^2+4*d*e*f^2+4*g*h*i^2-21096)*x*y+(-2*a*b^2-2*d*e^2-2*g*h^2+1104)*x*z^2+(4*a*b^2*c+4*d*e^2*f+4*g*h^2*i-18576)*x*z+(a^2*b^2+d^2*e^2+g^2*h^2-3540)*z^2+(-2*a^2*b^2*c-2*d^2*e^2*f-2*g^2*h^2*i+61272)*z+(-2*a*b^2*c^2-2*d*e^2*f^2-2*g*h^2*i^2+79848)*x+(a^2*c^2+d^2*f^2+g^2*i^2-4554)*y^2+(-2*a^2*b*c^2-2*d^2*e*f^2-2*g^2*h*i^2+69300)*y+(b^2*c^2+e^2*f^2+h^2*i^2-6120)*x^2+(c^2+f^2+i^2-126)*x^2*y^2+(-2*b*c^2-2*e*f^2-2*h*i^2+1692)*x^2*y+(b^2+e^2+h^2-93)*x^2*z^2+(-2*b^2*c-2*e^2*f-2*h^2*i+1476)*x^2*z+(-2*d-2*g-2*a+24)*x*y^2*z^2+(4*a*c+4*d*f+4*g*i-360)*x*y^2*z+(4*a*b+4*d*e+4*g*h-312)*x*y*z^2+(-8*a*b*c-8*d*e*f-8*g*h*i+5040)*x*y*z+(-2*f-2*i-2*c+36)*x^2*y^2*z+(-2*e-2*h-2*b+30)*x^2*y*z^2+(4*b*c+4*e*f+4*h*i-432)*x^2*y*z

So we want the coefficients of each term to be zero. There are 26 coefficients

eqs := {coeffs(q, {x, y, z})}; nops(%)

{-2*d-2*g-2*a+24, -2*e-2*h-2*b+30, -2*f-2*i-2*c+36, a^2+d^2+g^2-66, b^2+e^2+h^2-93, c^2+f^2+i^2-126, 4*a*b+4*d*e+4*g*h-312, -2*a*b^2-2*d*e^2-2*g*h^2+1104, -2*a^2*b-2*d^2*e-2*g^2*h+948, a^2*b^2+d^2*e^2+g^2*h^2-3540, 4*a*c+4*d*f+4*g*i-360, -2*a*c^2-2*d*f^2-2*g*i^2+1440, -2*a^2*c-2*d^2*f-2*g^2*i+1080, a^2*c^2+d^2*f^2+g^2*i^2-4554, 4*b*c+4*e*f+4*h*i-432, -2*b*c^2-2*e*f^2-2*h*i^2+1692, -2*b^2*c-2*e^2*f-2*h^2*i+1476, b^2*c^2+e^2*f^2+h^2*i^2-6120, -8*a*b*c-8*d*e*f-8*g*h*i+5040, 4*a*b*c^2+4*d*e*f^2+4*g*h*i^2-21096, 4*a*b^2*c+4*d*e^2*f+4*g*h^2*i-18576, 4*a^2*b*c+4*d^2*e*f+4*g^2*h*i-16056, -2*a*b^2*c^2-2*d*e^2*f^2-2*g*h^2*i^2+79848, -2*a^2*b*c^2-2*d^2*e*f^2-2*g^2*h*i^2+69300, -2*a^2*b^2*c-2*d^2*e^2*f-2*g^2*h^2*i+61272, a^2*b^2*c^2+d^2*e^2*f^2+g^2*h^2*i^2-268452}

26

Solve these equations for the unknowns {a,b,c...i}. Of course there are multiple solutions corresponding to permutations of the three terms in dioguess

sols := solve(eqs, {a, b, c, d, e, f, g, h, i})

{a = 1, b = 2, c = 3, d = 7, e = 8, f = 9, g = 4, h = 5, i = 6}, {a = 4, b = 5, c = 6, d = 7, e = 8, f = 9, g = 1, h = 2, i = 3}, {a = 1, b = 2, c = 3, d = 4, e = 5, f = 6, g = 7, h = 8, i = 9}, {a = 7, b = 8, c = 9, d = 4, e = 5, f = 6, g = 1, h = 2, i = 3}, {a = 4, b = 5, c = 6, d = 1, e = 2, f = 3, g = 7, h = 8, i = 9}, {a = 7, b = 8, c = 9, d = 1, e = 2, f = 3, g = 4, h = 5, i = 6}

eval(dioguess, sols[1])

(x-1)^2*(y-2)^2*(z-3)^2+(x-4)^2*(y-5)^2*(z-6)^2+(x-7)^2*(y-8)^2*(z-9)^2

NULL

Download dio.mw

No, I don't think you can get EllipticE(x,-1) from that integral. I think MMA is wrong, and the AI probably got the wrong result from MMA.

Edit - see below - MMA and Maple have different definitions.

Download EllipticE.mw

Here's a simple example - remembering a mutable structure like a Matrix is problematic.

This is a serious bug. I submitted an SCR.

forget.mw

I didn't know about symbolic regression, but it seems from your responses to @sand15 that you might also be interested in automatic selection from a class of models. He has provided a nice summary of the issues. Since he mentioned AIC and provided nice code for rational function fitting, I thought I would illustrate the principle of AIC for those functions.

Basically the idea is that more fitting parameters generally improve the fit but after a while the extra parameters are not meaningful (overfitting). AIC quantifies this tradeoff into one parameter, AIC. I recklessly ignored the full rank warnings; this is just to give you some idea of the method.

One can also use an F-ratio test to see whether a model with another parameter is statistically significant. Here you need to choose a confidence level, and it is not always clear what to use. I used to use F-ratio (at the 1% level), but more recently switched to AIC, though I have the impression that it still overfits more that I would like; that may just prove I'm too cautious. AIC can select between different classes of models, but you have to generate them in some way, which I guess is what symbolic regression does.

At the end of the day your data looks suspiciously noise-free, and the key issue may be more of finding what type of function would look like that (with less that the 16 parameters AIC decided on) than the regression itself. That still seems like a human endeavour.

@sand15's FitRationalFraction procedure and the dataset are in the startup code

restart;

kernelopts(version);

`Maple 2025.2, X86 64 WINDOWS, Nov 11 2025, Build ID 1971053`

X := <map2(op, 1, dataset)>:
Y := <map2(op, 2, dataset)>:
n := nops(dataset);

101

Fit all rational fraction models with numerator/denominator degrees between 5 and 10

AIC:=Array(5..10,5..10):

for ij in indices(AIC) do
  sij := ij[];
  F := FitRationalFraction(ij, X, Y, AllResults=true):
  S := F[1]["residualsumofsquares"];
  p := numelems(F[1]["parametervalues"]);
  fit[sij] := F[2];
  AIC[sij]:=evalf(n*ln(2*Pi)-n*ln(n)+n+n*ln(S)+2*(p+1));
end do:

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

Warning, model is not of full rank

In all rows and columns, the AIC gets better (more negative) and then worse (as overfitting occurs).

AIC;

`Array(5..10, 5..10, {})`

We want the fit with the most negative AIC

min(AIC);
min[index](AIC);
bestfit:=fit[%];

HFloat(-1772.0130337707733)

7, 9

y = (HFloat(5.639522374600771e-5)-HFloat(0.01288317349838677)*x-HFloat(0.06604775314173278)*x^2+HFloat(0.15402604574862966)*x^3-HFloat(0.10061405755123216)*x^4+HFloat(0.023236449348067213)*x^5-HFloat(0.0019176140897419658)*x^6+HFloat(4.3721095224913685e-5)*x^7)/(-HFloat(2.4682505243289557e-5)*x^9-HFloat(0.029674002394674673)*x^7+HFloat(0.21654010768516482)*x^6+HFloat(0.0018072506978093039)*x^8-HFloat(2.232927596702025)*x+HFloat(5.086432887393217)*x^2-HFloat(4.445396816679889)*x^3+HFloat(2.781300306907042)*x^4-HFloat(0.9769206707691607)*x^5+1)

plots:-display(
  plot(rhs(bestfit), x=(min..max)(X), color="SteelBlue")
  , Statistics:-ScatterPlot(X, Y, symbol=circle, symbolsize=10, color=black)
  , view=[(min..max)(X), (min..max)(Y)]
  , size=[1000, 400]
)

NULL

Download RationalFractionFitAIC.mw

I didn't try to figure out which solutions you might want; most of them have many a[i] and b[i] zero, so you may want to solve for different variables.

restart

with(PDEtools)

with(LinearAlgebra)

NULL

with(SolveTools)

undeclare(prime)

`There is no more prime differentiation variable; all derivatives will be displayed as indexed functions`

(1)

ode := (diff(diff(diff(diff(U(xi), xi), xi), xi), xi))*`&epsilon;`-(-6*w^2*`&epsilon;`+alpha)*(diff(diff(U(xi), xi), xi))-U(xi)*(3*w^4*`&epsilon;`-alpha*w^2-4*mu*U(xi)^2+k)

(diff(diff(diff(diff(U(xi), xi), xi), xi), xi))*epsilon-(-6*epsilon*w^2+alpha)*(diff(diff(U(xi), xi), xi))-U(xi)*(3*w^4*epsilon-alpha*w^2-4*mu*U(xi)^2+k)

(2)

F := sum(a[i]*G(xi)^i, i = 0 .. 2)+sum(b[i]*G(xi)^(-i), i = 1 .. 2)

a[0]+a[1]*G(xi)+a[2]*G(xi)^2+b[1]/G(xi)+b[2]/G(xi)^2

(3)

Y := G(xi) = sech(h*xi)

Y1 := (diff(G(xi), xi))^2 = h^2*G(xi)^2*(1-G(xi)^2)

odetest(Y, Y1)

0

(4)

Y2 := diff(G(xi), xi) = sqrt(h^2*G(xi)^2*(1-G(xi)^2))

diff(G(xi), xi) = (h^2*G(xi)^2*(1-G(xi)^2))^(1/2)

(5)

Look, ma, no square roots!

UU := U(xi) = dsubs(Y2, F)

U(xi) = (a[2]*G(xi)^4+a[1]*G(xi)^3+a[0]*G(xi)^2+b[1]*G(xi)+b[2])/G(xi)^2

(6)

L := numer(normal(eval(ode, UU)))

12*G(xi)^6*mu*a[1]^2*b[2]+12*G(xi)^6*mu*a[2]*b[1]^2-3*G(xi)^4*epsilon*w^4*b[2]+G(xi)^5*alpha*w^2*b[1]+12*G(xi)^5*mu*a[0]^2*b[1]+12*G(xi)^5*mu*a[1]*b[1]^2+G(xi)^4*alpha*w^2*b[2]+12*G(xi)^4*mu*a[0]^2*b[2]+12*G(xi)^4*mu*a[0]*b[1]^2+12*G(xi)^4*mu*a[2]*b[2]^2+12*G(xi)^3*mu*a[1]*b[2]^2+12*G(xi)^2*mu*a[0]*b[2]^2+12*G(xi)^2*mu*b[1]^2*b[2]+12*G(xi)*mu*b[1]*b[2]^2+2*G(xi)^7*(diff(diff(diff(diff(G(xi), xi), xi), xi), xi))*epsilon*a[2]+6*G(xi)^6*(diff(diff(G(xi), xi), xi))^2*epsilon*a[2]+G(xi)^6*(diff(diff(diff(diff(G(xi), xi), xi), xi), xi))*epsilon*a[1]-G(xi)^4*(diff(diff(diff(diff(G(xi), xi), xi), xi), xi))*epsilon*b[1]+6*G(xi)^3*(diff(diff(G(xi), xi), xi))^2*epsilon*b[1]+24*G(xi)*(diff(G(xi), xi))^4*epsilon*b[1]-2*G(xi)^3*(diff(diff(diff(diff(G(xi), xi), xi), xi), xi))*epsilon*b[2]+18*G(xi)^2*(diff(diff(G(xi), xi), xi))^2*epsilon*b[2]-2*G(xi)^7*(diff(diff(G(xi), xi), xi))*alpha*a[2]-2*G(xi)^6*(diff(G(xi), xi))^2*alpha*a[2]-G(xi)^6*(diff(diff(G(xi), xi), xi))*alpha*a[1]+G(xi)^4*(diff(diff(G(xi), xi), xi))*alpha*b[1]-2*G(xi)^3*(diff(G(xi), xi))^2*alpha*b[1]+2*G(xi)^3*(diff(diff(G(xi), xi), xi))*alpha*b[2]-6*G(xi)^2*(diff(G(xi), xi))^2*alpha*b[2]+12*G(xi)^11*mu*a[1]*a[2]^2+12*G(xi)^10*mu*a[0]*a[2]^2+12*G(xi)^10*mu*a[1]^2*a[2]-3*G(xi)^8*epsilon*w^4*a[2]+12*G(xi)^9*mu*a[2]^2*b[1]-3*G(xi)^7*epsilon*w^4*a[1]+G(xi)^8*alpha*w^2*a[2]+12*G(xi)^8*mu*a[0]^2*a[2]+12*G(xi)^8*mu*a[0]*a[1]^2+12*G(xi)^8*mu*a[2]^2*b[2]-3*G(xi)^6*epsilon*w^4*a[0]+G(xi)^7*alpha*w^2*a[1]+12*G(xi)^7*mu*a[0]^2*a[1]+12*G(xi)^7*mu*a[1]^2*b[1]-3*G(xi)^5*epsilon*w^4*b[1]+G(xi)^6*alpha*w^2*a[0]+120*(diff(G(xi), xi))^4*epsilon*b[2]+4*G(xi)^12*mu*a[2]^3+4*G(xi)^9*mu*a[1]^3-G(xi)^8*k*a[2]+4*G(xi)^6*mu*a[0]^3-G(xi)^7*k*a[1]-G(xi)^6*k*a[0]-G(xi)^5*k*b[1]+4*G(xi)^3*mu*b[1]^3-G(xi)^4*k*b[2]+4*mu*b[2]^3+6*G(xi)^6*(diff(diff(G(xi), xi), xi))*epsilon*w^2*a[1]-6*G(xi)^4*(diff(diff(G(xi), xi), xi))*epsilon*w^2*b[1]+12*G(xi)^3*(diff(G(xi), xi))^2*epsilon*w^2*b[1]-12*G(xi)^3*(diff(diff(G(xi), xi), xi))*epsilon*w^2*b[2]+36*G(xi)^2*(diff(G(xi), xi))^2*epsilon*w^2*b[2]+24*G(xi)^9*mu*a[0]*a[1]*a[2]+24*G(xi)^8*mu*a[1]*a[2]*b[1]+24*G(xi)^7*mu*a[0]*a[2]*b[1]+24*G(xi)^7*mu*a[1]*a[2]*b[2]+24*G(xi)^6*mu*a[0]*a[1]*b[1]+24*G(xi)^6*mu*a[0]*a[2]*b[2]+24*G(xi)^5*mu*a[0]*a[1]*b[2]+24*G(xi)^5*mu*a[2]*b[1]*b[2]+24*G(xi)^4*mu*a[1]*b[1]*b[2]+24*G(xi)^3*mu*a[0]*b[1]*b[2]+8*G(xi)^6*(diff(G(xi), xi))*(diff(diff(diff(G(xi), xi), xi), xi))*epsilon*a[2]+8*G(xi)^3*(diff(G(xi), xi))*(diff(diff(diff(G(xi), xi), xi), xi))*epsilon*b[1]-36*G(xi)^2*(diff(G(xi), xi))^2*(diff(diff(G(xi), xi), xi))*epsilon*b[1]+24*G(xi)^2*(diff(G(xi), xi))*(diff(diff(diff(G(xi), xi), xi), xi))*epsilon*b[2]-144*G(xi)*(diff(G(xi), xi))^2*(diff(diff(G(xi), xi), xi))*epsilon*b[2]+12*G(xi)^7*(diff(diff(G(xi), xi), xi))*epsilon*w^2*a[2]+12*G(xi)^6*(diff(G(xi), xi))^2*epsilon*w^2*a[2]

(7)

Still have derivatives of G, so

L1 := dsubs(Y2, L)

120*G(xi)^12*epsilon*h^4*a[2]+24*G(xi)^11*epsilon*h^4*a[1]-120*G(xi)^10*epsilon*h^4*a[2]-20*G(xi)^9*epsilon*h^4*a[1]+6*G(xi)^10*alpha*h^2*a[2]+16*G(xi)^8*h^4*epsilon*a[2]+2*G(xi)^9*alpha*h^2*a[1]+G(xi)^7*epsilon*h^4*a[1]-4*G(xi)^8*h^2*alpha*a[2]-8*G(xi)^6*epsilon*h^4*b[2]-G(xi)^7*h^2*alpha*a[1]+G(xi)^5*h^4*epsilon*b[1]+2*G(xi)^6*alpha*h^2*b[2]+16*G(xi)^4*h^4*epsilon*b[2]-G(xi)^5*h^2*alpha*b[1]-4*G(xi)^4*h^2*alpha*b[2]-36*G(xi)^10*epsilon*h^2*w^2*a[2]-12*G(xi)^9*epsilon*h^2*w^2*a[1]+24*G(xi)^8*h^2*epsilon*w^2*a[2]+6*G(xi)^7*h^2*epsilon*w^2*a[1]-12*G(xi)^6*epsilon*h^2*w^2*b[2]+6*G(xi)^5*h^2*epsilon*w^2*b[1]+24*G(xi)^4*h^2*epsilon*w^2*b[2]+12*G(xi)^6*mu*a[1]^2*b[2]+12*G(xi)^6*mu*a[2]*b[1]^2-3*G(xi)^4*epsilon*w^4*b[2]+G(xi)^5*alpha*w^2*b[1]+12*G(xi)^5*mu*a[0]^2*b[1]+12*G(xi)^5*mu*a[1]*b[1]^2+G(xi)^4*alpha*w^2*b[2]+12*G(xi)^4*mu*a[0]^2*b[2]+12*G(xi)^4*mu*a[0]*b[1]^2+12*G(xi)^4*mu*a[2]*b[2]^2+12*G(xi)^3*mu*a[1]*b[2]^2+12*G(xi)^2*mu*a[0]*b[2]^2+12*G(xi)^2*mu*b[1]^2*b[2]+12*G(xi)*mu*b[1]*b[2]^2+12*G(xi)^11*mu*a[1]*a[2]^2+12*G(xi)^10*mu*a[0]*a[2]^2+12*G(xi)^10*mu*a[1]^2*a[2]-3*G(xi)^8*epsilon*w^4*a[2]+12*G(xi)^9*mu*a[2]^2*b[1]-3*G(xi)^7*epsilon*w^4*a[1]+G(xi)^8*alpha*w^2*a[2]+12*G(xi)^8*mu*a[0]^2*a[2]+12*G(xi)^8*mu*a[0]*a[1]^2+12*G(xi)^8*mu*a[2]^2*b[2]-3*G(xi)^6*epsilon*w^4*a[0]+G(xi)^7*alpha*w^2*a[1]+12*G(xi)^7*mu*a[0]^2*a[1]+12*G(xi)^7*mu*a[1]^2*b[1]-3*G(xi)^5*epsilon*w^4*b[1]+G(xi)^6*alpha*w^2*a[0]+4*G(xi)^12*mu*a[2]^3+4*G(xi)^9*mu*a[1]^3-G(xi)^8*k*a[2]+4*G(xi)^6*mu*a[0]^3-G(xi)^7*k*a[1]-G(xi)^6*k*a[0]-G(xi)^5*k*b[1]+4*G(xi)^3*mu*b[1]^3-G(xi)^4*k*b[2]+4*mu*b[2]^3+24*G(xi)^9*mu*a[0]*a[1]*a[2]+24*G(xi)^8*mu*a[1]*a[2]*b[1]+24*G(xi)^7*mu*a[0]*a[2]*b[1]+24*G(xi)^7*mu*a[1]*a[2]*b[2]+24*G(xi)^6*mu*a[0]*a[1]*b[1]+24*G(xi)^6*mu*a[0]*a[2]*b[2]+24*G(xi)^5*mu*a[0]*a[1]*b[2]+24*G(xi)^5*mu*a[2]*b[1]*b[2]+24*G(xi)^4*mu*a[1]*b[1]*b[2]+24*G(xi)^3*mu*a[0]*b[1]*b[2]

(8)

indets(L1)

{alpha, epsilon, h, k, mu, w, xi, a[0], a[1], a[2], b[1], b[2], G(xi)}

(9)

eqs := {coeffs(collect(L1, G(xi)), G(xi))}

{4*mu*b[2]^3, 12*mu*b[1]*b[2]^2, 120*epsilon*h^4*a[2]+4*mu*a[2]^3, 12*mu*a[0]*b[2]^2+12*mu*b[1]^2*b[2], 24*epsilon*h^4*a[1]+12*mu*a[1]*a[2]^2, 24*mu*a[0]*b[1]*b[2]+12*mu*a[1]*b[2]^2+4*mu*b[1]^3, -120*epsilon*h^4*a[2]-36*epsilon*h^2*w^2*a[2]+6*alpha*h^2*a[2]+12*mu*a[0]*a[2]^2+12*mu*a[1]^2*a[2], -20*epsilon*h^4*a[1]-12*epsilon*h^2*w^2*a[1]+2*alpha*h^2*a[1]+24*mu*a[0]*a[1]*a[2]+4*mu*a[1]^3+12*mu*a[2]^2*b[1], 16*epsilon*h^4*b[2]+24*epsilon*h^2*w^2*b[2]-3*epsilon*w^4*b[2]-4*alpha*h^2*b[2]+alpha*w^2*b[2]+12*mu*a[0]^2*b[2]+12*mu*a[0]*b[1]^2+24*mu*a[1]*b[1]*b[2]+12*mu*a[2]*b[2]^2-k*b[2], epsilon*h^4*b[1]+6*epsilon*h^2*w^2*b[1]-3*epsilon*w^4*b[1]-alpha*h^2*b[1]+alpha*w^2*b[1]+12*mu*a[0]^2*b[1]+24*mu*a[0]*a[1]*b[2]+12*mu*a[1]*b[1]^2+24*mu*a[2]*b[1]*b[2]-k*b[1], 16*epsilon*h^4*a[2]+24*epsilon*h^2*w^2*a[2]-3*epsilon*w^4*a[2]-4*alpha*h^2*a[2]+alpha*w^2*a[2]+12*mu*a[0]^2*a[2]+12*mu*a[0]*a[1]^2+24*mu*a[1]*a[2]*b[1]+12*mu*a[2]^2*b[2]-k*a[2], epsilon*h^4*a[1]+6*epsilon*h^2*w^2*a[1]-3*epsilon*w^4*a[1]-alpha*h^2*a[1]+alpha*w^2*a[1]+12*mu*a[0]^2*a[1]+24*mu*a[0]*a[2]*b[1]+12*mu*a[1]^2*b[1]+24*mu*a[1]*a[2]*b[2]-k*a[1], -8*epsilon*h^4*b[2]-12*epsilon*h^2*w^2*b[2]-3*epsilon*w^4*a[0]+2*alpha*h^2*b[2]+alpha*w^2*a[0]+4*mu*a[0]^3+24*mu*a[0]*a[1]*b[1]+24*mu*a[0]*a[2]*b[2]+12*mu*a[1]^2*b[2]+12*mu*a[2]*b[1]^2-k*a[0]}

(10)

indets(eqs); nops(eqs)

{alpha, epsilon, h, k, mu, w, a[0], a[1], a[2], b[1], b[2]}



13

(11)

solution1 := solve(eqs, [alpha, mu, w, a[0], a[1], a[2], b[1], b[2]], explicit); nops(%)

28

(12)

ans1 := solution1[1]

[alpha = (epsilon*h^4+6*epsilon*h^2*w^2-3*epsilon*w^4-k)/((h-w)*(h+w)), mu = 0, w = w, a[0] = 0, a[1] = 0, a[2] = 0, b[1] = b[1], b[2] = 0]

(13)

ode1 := eval(ode, ans1)

(diff(diff(diff(diff(U(xi), xi), xi), xi), xi))*epsilon-(-6*w^2*epsilon+(epsilon*h^4+6*epsilon*h^2*w^2-3*epsilon*w^4-k)/((h-w)*(h+w)))*(diff(diff(U(xi), xi), xi))-U(xi)*(3*w^4*epsilon-(epsilon*h^4+6*epsilon*h^2*w^2-3*epsilon*w^4-k)*w^2/((h-w)*(h+w))+k)

(14)

UU1 := eval(eval(UU, ans1), Y)

U(xi) = b[1]/sech(h*xi)

(15)

odetest(UU1, ode1)

0

(16)

NULL

Download test-F-p2.mw

@sand15 I think you meant rhs(sol) in unapply. Then the second step can be simpler:

Sol := unapply(rhs(sol), x);
eval(IC, y = Sol);

Edit: handling of terms like ln(r) improved.

https://www.mapleprimes.com/questions/242062-Collect-Using-Pattern

restart;

We want to collect A with respect to r, including symbolic exponents, in order to get B. I've added a constant term to the OP's example, to further test the method.
It is not clear from the question if the order matters, or what it would be for more complicated exponents.

For simplicity, assume that the order of exponents is just the default sort order, which would work here.

A:=r^(2*a)+r^2*(1+a+r^(2*a)) + r + a*r + a;
B:=a+(1+a)*r+(1+a)*r^2+r^(2*a)+r^(2+2*a);

r^(2*a)+r^2*(1+a+r^(2*a))+r+a*r+a

a+(1+a)*r+(1+a)*r^2+r^(2*a)+r^(2+2*a)

Notice that Maple's automatic simplification may frustrate any attempt to get a desired order, e.g., the following is already collected, but does not retain the input order, and is perhaps not in the expected order

r^3 + a*r^2 + r;

a*r^2+r^3+r

The reason collect does not work is that it is for polynomials, which have integer exponents but not symbolic ones.
The following finds the exponent wrt r for any exponent not containing r

ex := (y,r) -> r*diff(y,r)/y;

proc (y, r) options operator, arrow; r*(diff(y, r))/y end proc

Examples. The presence of r in the second case indicates we should probably just leave this alone (this is done in the procedure below).

ex(7*r^(2*tan(a)), r);
ex(a*ln(r), r);

2*tan(a)

1/ln(r)

Expand, find the terms and their corresponding exponents and coefficients. (assumes it is type `+`)

terms := [op(expand(A))];
exps := expand(ex~(terms, r));
cfs := zip((t,e)->expand(t/r^e), terms, exps);

[(r^a)^2, r^2, a*r^2, r^2*(r^a)^2, r, a*r, a]

[2*a, 2, 2, 2+2*a, 1, 1, 0]

[1, 1, a, 1, 1, a, a]

Sort them

exps2, p := sort(exps, output = [sorted, permutation]);
cfs2 := cfs[p];

[0, 1, 1, 2, 2, 2*a, 2+2*a], [7, 5, 6, 2, 3, 1, 4]

[a, 1, a, 1, a, 1, 1]

Assemble the results

s:=0: cf:=cfs2[1]: expt:=exps2[1]:
for i from 2 to nops(exps2) do
  if exps2[i] = expt then
    cf += cfs2[i]
  else
    s += cf*r^expt;
    expt := exps2[i];
    cf := cfs2[i]
  end if;
end do;
s += cf*r^expt;

a+(1+a)*r+(1+a)*r^2+r^(2*a)+r^(2+2*a)

As a procedure.

Collect := proc(expr, x::name)
local zz, ex, term, cfs, exps, p, s, cf, i;
if expr::function then return expr end if;
for i,term in expand(expr)+zz do # zz forces type `+`
  ex := expand(x*diff(term,x)/term);
  if has(ex, x) then
     cfs[i] := term;
     exps[i] := 0;
  else
     exps[i] := ex;
     cfs[i] := expand(term/x^ex)
  end if;
end do;
exps := convert(exps, list);
cfs := convert(cfs, list);
exps, p := sort(exps, 'output' = ['sorted', 'permutation']);
cfs := cfs[p];
s := 0;
cf := cfs[1];
ex := exps[1]:
for i from 2 to nops(exps) do
  if exps[i] = ex then
    cf += cfs[i]
  else
    s += cf*x^ex;
    ex := exps[i];
    cf := cfs[i]
  end if;
end do;
s += cf*x^ex - zz;
end proc:

Test

Collect(A + ln(r), r);

a+ln(r)+(1+a)*r+(1+a)*r^2+r^(2*a)+r^(2+2*a)

Collect(r^3 + a*r^2 + r, r);

a*r^2+r^3+r

Collect(ln(x)+3*x^2, x);

ln(x)+3*x^2

x^f(x) is left alone, i.e., is treated as a constant term.

Collect(3*x^2 + 2*x^x, x);

3*x^2+2*x^x



Download CollectSymbolicExponents.mw

sqrt(1-cos(x)^2);
simplify(%,{cos(x)^2=1-sin(x)^2});

For some reason, the original simplify gives a numerator/denominator, with sqrt(1-t^2) in both.  If expand is used first then we don't have numerator/denominator, Then simplify can deal with the diffs. As well the denominator sqrt(1-t^2) might cancel or be simpler. So simplify(expand(B)) works here. The collect serves the same purpose as expand - giving priority to the diffs means we get a polynomial in diffs and not numerator/denominator, which then simplifies. The collect can be just wrt diff, so simplify(collect(B,diff))works.

As far as I can see, there is some error in the paper. Maybe one of the other case(s) works.

Download pde.mw

1 2 3 4 5 6 7 Last Page 1 of 86
