I am a retired professor of chemistry at the University of Victoria, BC, Canada. My research areas are electrochemistry and surface science. I have been a user of Maple since about 1990.

MaplePrimes Activity


These are answers submitted by dharr

local/global confusion...

dharr 9449
July 07 2026
1 1

One solution is to move the ode inside MoveRod as you had in the Rod_triangle code. But a better solution is just to move the ics and dsolve outside MoveRod and then get rid of MoveRod altogether - it was defined and then immediately invoked only once.  Like this:

Rod_parabola.mw

The problem is that when ode is defined outside MoveRod, x is a global. Then inside MoveRod you declare x as a local, so the dsolve command has two x's that look the same but are not. You can confirm this by changing dsolve to ddsolve, then after MoveRod(); add indets(%,function). Towards the end you will see x(t) appears twice.

updates...

dharr 9449
July 06 2026
1 0

You should be able to update to 2025.2 through Tools -> check for updates.

If you mean the Customer Support Updates and the SupportTools package that makes small updates between numbered updates, that was brought in in Maple 2026. I recall it was experimental during 2025, someone may be able to help you install it manually (search Mapleprimes, perhaps?), but probably there wasn't much beyond the 2025.2 update.

series...

dharr 9449
July 06 2026
1 0

The message means there are two variables (nu and x) and it does not know which to expand in. It does not seem to know the general nu case. But this can be done in other ways:

Download Bessel.mw

seq...

dharr 9449
July 04 2026
2 0

Simplest way is seq:

seq(ithprime(b), b = 1..19);

?dsolve, numeric, interactive...

dharr 9449
July 04 2026
2 1

It is hard to find but is at ?dsolve,numeric,interactive.

2016 -> 2026...

dharr 9449
July 01 2026
1 1

I'm not sure I completely understand what you want to do. The simplest is to just open your 2016 worksheet in Maple 2026. You may get a warning message but I think almost everything will work the same; if not you can ask a specific question about that here.

Since you want to use 1D input in 2026, go to the File tab in the top ribbon, and then in the bottom-right corner of the drop-menu choose "options". That brings up a popup menu. Choose its Display tab, and then choose Input Display as Maple Notation and choose Apply Globally or Apply to Session. The output display could also be changed, though that seems more unusual.

If you just want to copy a few lines you can directly copy from 2016 to 2026. If you haven't set your Input Display to Maple Notation, you need to use Ctrl-m on the input line just before you paste to ensure that input line is in 1D mode.

pde2...

dharr 9449
June 21 2026
1 8

As you used, the pde2 paper must be using the ordinary derivative. With some additional assumptions it can give Eq 3.5.

Download pde2.mw

some success...

dharr 9449
June 21 2026
1 0

I'm assuming the notation (lambda - nu)r means pochhammer. If so, straightforward evaluation of the double sum works in some cases.

>

restart
>

F := proc (lambda, nu, kappa, mu, alpha, beta, x) options operator, arrow; GAMMA(kappa+lambda+1)*GAMMA(mu+nu+1)*(Sum(Sum(pochhammer(lambda-kappa, r)*pochhammer(nu-mu, s)*BesselJ(kappa+lambda+r, alpha*x)*BesselJ(mu+nu+s, beta*sqrt(1-x^2))*((1/2)*alpha*x)^(kappa+lambda+r)*((1/2)*beta*sqrt(1-x^2))^(mu+nu+s)/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(lambda+r+1)*GAMMA(nu+s+1)), r = 0 .. infinity), s = 0 .. infinity)) end proc

proc (lambda, nu, kappa, mu, alpha, beta, x) options operator, arrow; GAMMA(kappa+lambda+1)*GAMMA(mu+nu+1)*(Sum(Sum(pochhammer(lambda-kappa, r)*pochhammer(nu-mu, s)*BesselJ(kappa+lambda+r, alpha*x)*BesselJ(mu+nu+s, beta*sqrt(1-x^2))*((1/2)*alpha*x)^(kappa+lambda+r)*((1/2)*beta*sqrt(1-x^2))^(mu+nu+s)/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(lambda+r+1)*GAMMA(nu+s+1)), r = 0 .. infinity), s = 0 .. infinity)) end proc

Success:

>

F(1/2, 1/2, 1/2, 1/2, alpha, beta, x); value(%)

Sum(Sum(pochhammer(0, r)*pochhammer(0, s)*BesselJ(1+r, alpha*x)*BesselJ(1+s, beta*(-x^2+1)^(1/2))*((1/2)*alpha*x)^(1+r)*((1/2)*beta*(-x^2+1)^(1/2))^(1+s)/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(3/2+r)*GAMMA(3/2+s)), r = 0 .. infinity), s = 0 .. infinity)

BesselJ(1, alpha*x)*BesselJ(1, beta*(-x^2+1)^(1/2))*alpha*x*beta*(-x^2+1)^(1/2)/Pi

Success

>

F(-1/2, 1/2, 1/2, 1/2, alpha, beta, x); value(%)

Sum(Sum(pochhammer(-1, r)*pochhammer(0, s)*BesselJ(r, alpha*x)*BesselJ(1+s, beta*(-x^2+1)^(1/2))*((1/2)*alpha*x)^r*((1/2)*beta*(-x^2+1)^(1/2))^(1+s)/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(1/2+r)*GAMMA(3/2+s)), r = 0 .. infinity), s = 0 .. infinity)

BesselJ(0, alpha*x)*BesselJ(1, beta*(-x^2+1)^(1/2))*beta*(-x^2+1)^(1/2)/Pi-(1/2)*BesselJ(1, alpha*x)*BesselJ(1, beta*(-x^2+1)^(1/2))*alpha*x*beta*(-x^2+1)^(1/2)/Pi

Success

>

F(1/2, -1/2, 1/2, 1/2, alpha, beta, x); value(%)

Sum(Sum(pochhammer(0, r)*pochhammer(-1, s)*BesselJ(1+r, alpha*x)*BesselJ(s, beta*(-x^2+1)^(1/2))*((1/2)*alpha*x)^(1+r)*((1/2)*beta*(-x^2+1)^(1/2))^s/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(3/2+r)*GAMMA(1/2+s)), r = 0 .. infinity), s = 0 .. infinity)

BesselJ(1, alpha*x)*BesselJ(0, beta*(-x^2+1)^(1/2))*alpha*x/Pi-(1/2)*BesselJ(1, alpha*x)*BesselJ(1, beta*(-x^2+1)^(1/2))*alpha*x*beta*(-x^2+1)^(1/2)/Pi

Reduces to a single sum

>

F(1/2, 1/2, -1/2, 1/2, alpha, beta, x); value(%)

Sum(Sum(pochhammer(1, r)*pochhammer(0, s)*BesselJ(r, alpha*x)*BesselJ(1+s, beta*(-x^2+1)^(1/2))*((1/2)*alpha*x)^r*((1/2)*beta*(-x^2+1)^(1/2))^(1+s)/(2^(r+s)*factorial(r)*factorial(s)*GAMMA(3/2+r)*GAMMA(3/2+s)), r = 0 .. infinity), s = 0 .. infinity)

sum(pochhammer(1, r)*BesselJ(r, alpha*x)*BesselJ(1, beta*(-x^2+1)^(1/2))*((1/2)*alpha*x)^r*beta*(-x^2+1)^(1/2)/(2^r*factorial(r)*GAMMA(3/2+r)*Pi^(1/2)), r = 0 .. infinity)

>

NULL

Download Hughes2.mw

evala plus...

dharr 9449
June 13 2026
3 3
>

restart
>

interface(version)

`Standard Worksheet Interface, Maple 2026.1, Windows 11, April 28 2026 Build ID 2011354`

>

expr := sqrt(x__0+1)*sqrt(-2*beta^2*x__0-2*beta^2+4)*sqrt(-(x__0+1)*(beta^2-1))/((beta^2*x__0+beta^2-2)*(beta^2*x__0+beta^2-x__0-1)); result := 2/(sqrt(-beta^2+1)*sqrt(-2*beta^2*x__0-2*beta^2+4)); assumptions := 0 < x__0 and x__0 < 1, 0 < beta and beta < 1

(x__0+1)^(1/2)*(-2*beta^2*x__0-2*beta^2+4)^(1/2)*(-(x__0+1)*(beta^2-1))^(1/2)/((beta^2*x__0+beta^2-2)*(beta^2*x__0+beta^2-x__0-1))

2/((-beta^2+1)^(1/2)*(-2*beta^2*x__0-2*beta^2+4)^(1/2))

0 < x__0 and x__0 < 1, 0 < beta and beta < 1

The result has square roots on the denominator. Removal of square roots from the denominor and putting them on the numerator is a task for evala or rationalize, so try applying these to the reciprocal.

>

recip := evala(1/expr); rationalize(1/expr)

(1/2)*(-(x__0+1)*(beta^2-1))^(1/2)*(-2*beta^2*x__0-2*beta^2+4)^(1/2)/(x__0+1)^(1/2)

(1/2)*(-beta^2*x__0-beta^2+x__0+1)^(1/2)*(-2*beta^2*x__0-2*beta^2+4)^(1/2)/(x__0+1)^(1/2)

The evala result needs only cancellation of the common factor sqrt(x__0+1) to give the required result, suggesting it will work with the required assumptions

>

`assuming`([simplify(recip)], [assumptions])

(1/2)*(-beta^2+1)^(1/2)*(4-2*(x__0+1)*beta^2)^(1/2)

So the following works

>

`assuming`([1/simplify(evala(1/expr))], [assumptions]); simplify(%-result)

2/((-beta^2+1)^(1/2)*(4-2*(x__0+1)*beta^2)^(1/2))

0

>

NULL

Download simplify.mw

[4,3,1] Solution...

dharr 9449
June 03 2026
1 5

[Edit: [4,2,1] corrected to [4,3,1]]. Here is the procedure for the [4,3,1] case. I assumed the Hirota transformation result was given correctly in the paper.

Download t1.mw

near enough...

dharr 9449
May 12 2026
0 19

@salim-barzani The paper seems to have several errors

fp2.mw

(1) volumes and areas...

dharr 9449
May 08 2026
3 6

Here for (1): [edit: updated to use the InRadius.]

>

restart
>

with(geom3d); _local(O)

Define o as the origin, and C and O as cube and octahedron. The cube has sides of length 1. The corners of the octahedron will touch the centres of the faces of the cube, so the circumsphere of the octahedron will be equal to 1/2, which can be found as the radius of the in-sphere of the cube.

>

point(o, 0, 0, 0); cube(C, o, side = 1); inR := InRadius(C); octahedron(O, o, inR)

1/2

>

draw([C(cutout = .85), O])

And the ratio of the volumes is

>

vOvC := volume(O)/volume(C)

1/6

For the cube inside the octahedron, its corners touch the centres of faces of the octahedron. So we want the distance of the centre of a face from the origin, which is the InRadius

>

d := InRadius(O)

(1/6)*3^(1/2)

So the cube inside has circumsphere of radius d

>

cube(C__2, o, d)
>

draw([C(cutout = .85), O(cutout = .85), C__2])

The ratio of volumes of successive cubes is

>

rc := volume(C__2)/volume(C)

1/27

And so the sum of all the volumes of the cubes is a geometric series "1+1/(27)+(1/(27))^(2)+..."

>

cubesvol := 1/(1-rc)

27/26

The volume of the next octahedron is 1/6 of the volume of C__2, from which we get the ratio of volumes of successive octahedra is also 1/27

>

vO2 := vOvC*volume(C__2); ro := vO2/volume(O)

1/162

1/27

Summing the geoemetric series, starting at the volume of the first octahedron gives

>

octsvol := volume(O)/(1-ro)

9/52

And the grand total volume is

>

allvol := cubesvol+octsvol

63/52

For the surface areas we have for the cubes

>

ac := area(C__2)/area(C); cubesarea := area(C)/(1-ac)

1/9

27/4

and for the octahedra it is again the same ratio

>

aO2 := area(O)*area(C__2)/area(C); ao := aO2/area(O)

(1/9)*3^(1/2)

1/9

>

octsarea := area(O)/(1-ao)

(9/8)*3^(1/2)

And the grand total area is

>

cubesarea+octsarea

27/4+(9/8)*3^(1/2)

>

``

Download cubeoct2.mw

Conflict with Statistics...

dharr 9449
May 05 2026
1 1

The error message mentions a problem with Statistics:-Remove, so the problem is that the dataframe Remove and the Statistics Remove commands are being confused. If you remove your with(Statistics) line, you will see that many of your Removes now work. To use it while the Statistics package is loaded you can use

df1:-Remove(df1, A);

or

DataFrame:-Remove(df1, A);

This syntax is because the dataframes are implemented as Maple Objects, but this use of Remove doesn't seem to be well documented.

ZehfussReplace...

dharr 9449
April 21 2026
2 5

I think this is what you want. Maybe you want to use uneval quotes around Determinant in the last line of the transformer procedure (or use %Determinant)

>

restart
>

with(LinearAlgebra)
>

A := Matrix(2, 2, symbol = a); B := Matrix(3, 3, symbol = b)
>

ZehfussReplace := proc(expr::uneval)
  uses LinearAlgebra;
  subsindets(expr,
    specfunc(specfunc('KroneckerProduct'),'Determinant'),
    proc(q)
      local AB;
      AB:=op(op(q));
      if not eval([AB])::['Matrix'('square'),'Matrix'('square')] then return eval(q) end if;
      Determinant(AB[1])^(upperbound(AB[2])[1])*Determinant(AB[2])^(upperbound(AB[1])[1])
    end proc
   );
end proc:
>

ZehfussReplace(Determinant(KroneckerProduct(A, B))+2*Determinant(KroneckerProduct(A, A)))

(a[1, 1]*a[2, 2]-a[1, 2]*a[2, 1])^3*(b[1, 1]*b[2, 2]*b[3, 3]-b[1, 1]*b[2, 3]*b[3, 2]-b[1, 2]*b[2, 1]*b[3, 3]+b[1, 2]*b[2, 3]*b[3, 1]+b[1, 3]*b[2, 1]*b[3, 2]-b[1, 3]*b[2, 2]*b[3, 1])^2+2*(a[1, 1]*a[2, 2]-a[1, 2]*a[2, 1])^4

>

NULL

Download ZehfussReplace.mw

Convert to...

dharr 9449
April 18 2026
1 4

After inserting the table, select it all with the mouse (all cells now yellow). Then the right-click menu has "Convert To" with option "2-D math input", which will put prompts in each cell ready for 2-D math input. Is this what you want?
