## @nick999  Units appear to work bet...

Units appear to work better when all math is done at maple prompts rather than just typing 2d math into a document

When using units, I work in 2d math using Worksheet mode. This gives you

• the structure of input prompts
• the 2d math
• and the ability to use CTRL+Shift+U to enter units  (I find this quicker than using the mouse to choose units from the Units palette, and you don't see the Unit() syntax in your equations)

1) Maple doesnt seem to convert between different units of the same dimension. For example:

w:= 10*feet+6*inch;   simplify(w);  produces 10*feet+6*inch rather than 10.5 feet or 126 inch

and

b:= 1 inch * 12 inch/(1 feet * 1 feet); simplify(b); produces 12 inch^2/feet^2

Load with(Units[Simple]) before you do any units calculations. The result of 10.0*Unit('ft')+6.0*Unit('inch') will automatically be converted to meters

2) There isnt a way to specify output units.  For example:

w:= 100 inch;

A:= w^2;

produces 10,000 inch and there is no way to ask for A in terms of feet^2 (unless w is entered in feet)

Right click on the result and select "Units Formatting". In the dialog that pops up, enter ft^2 in "Custom Unit"

## @ThU Mathcad has an elegant and sim...

@ThU

Mathcad has an elegant and simple implementation of units. I find that Mathcad users come to Maple with the same expectation of units.

We're working on a long term plan to bring make units handling more intuitive, and more deeply ingrained into the system. The first step was the introduction of the Units[Simple] package last year. Expect to see more changes with the next release.

## Animated robot arm drawing a Maple Leaf...

Here's an animation of a robot arm drawing a Maple leaf, courtesy of this worksheet

## @Markiyan Hirnyk Your screen shows shows...

@Markiyan Hirnyk Your screen shows shows "Adult literacy rate, population 15+ years, gender parity index (GPI)"

The application uses "Adult literacy rate, population 15+ years, both sexes (%)" for the year 2015. As the title of the application here states, only subsaharan african countries are plotted (as such, Egypt is not plotted)

## @Markiyan Hirnyk The data comes from htt...

@Markiyan Hirnyk The data comes from http://data.uis.unesco.org/Index.aspx?queryid=166. Specifically, it's the adult literacy rate for both sexes, ages 15+. The complete application is here

## @Ramakrishnan The Organic Rankine Cycle ...

@Ramakrishnan The Organic Rankine Cycle application can be found here (and it's in the Application Gallery in Maple 2017). All the code is in the startup code region. In the application

• the flowchart is an image (that is, an image file created in another tool and placed on the plot with the background option)
• the text and numbers on the plot are textplots.

If you want box color to vary with the value of a variable, you'll need to construct the flowchart (i.e the boxes and the arrows) using plottools. Perhaps something like this

with(plottools):
with(ColorTools):
with(plots):
conditionalValue := 1.2:
colorList := [[0,79/255, 121/255], [221/255,231/255, 240/255]]:
colorValue := piecewise(conditionalValue > 1, colorList[1], colorList[2]):
p1:=rectangle([-2,1],[2,-1],color=Color("RGB",colorValue), style=surface):
p2 := textplot([2,1.4,sprintf("Value = %.1f",conditionalValue)],font=[Arial, Bold]):
display(p1, p2,scaling=constrained, view = [-5..5, -5..5], axes = none)

## PDE enhancements...

@Ramakrishnan You might be interested in this document:

Enhancements to PDE solvers in Maple 2017

## @Markiyan Hirnyk We already know :)...

@Markiyan Hirnyk We already know :)

Stefan

I'll let you know if we think Maple is a viable alternative.

Samir

## @mclaine Could you please email us a Mat...

@mclaine Could you please email a typical Mathcad worksheet to support@maplesoft.com (marked for my attention). I'd like to take a closer look, and perhaps provide a few recommendations. The technical context always matters

Maple will not, unless you specifically ask it to (with convert(B,unit_free))

If you're thinking about switching from Mathcad to Maple, I would not concentrate on directly reproducing your Mathcad units experience in Maple. The underlying implementation is too different.

Are you doing antenna design? I'm guessing from your previous questions and comments about units, scientific constants, and phasors.

## @mclaine I used to work for a Mathcad re...

@mclaine I used to work for a Mathcad reseller in tech support, so I know both products well.

Are you attemping to convert an existing Mathcad worksheet to Maple? If so, can you share the Mathcad worksheet? That would help us understand the context of your issue.

## Cooling Potential of a Zeer...

@Christopher2222 Here's a rough cut of an analysis.

 > with(ThermophysicalData): with(plots):

This function gives the coldest possible temperature (i.e. the wet bulb temperature) in a Zeer as a function of the air temperature

and the relative humidity

 > Twb_val := (Tdb_val, R_val) -> Property(Twb, HumidAir, Tdb = Tdb_val, R = R_val, pressure = 101325):

Range of relative humidities to plot:

 > R_val := [0.3, 0.4, 0.5, 0.6, 0.7]:
 > p1 := seq(plot(Twb_val(temp, R_val[i]), temp = 280 .. 310, adaptive = false, numpoints = 20), i = 1 .. 5):
 > p2 := seq(textplot([310, Twb_val(310, R_val[i]), sprintf("R = %.1f",R_val[i])]), i = 1 .. 5):
 > display(p1, p2, labels = ["Air Temperature (K)", "Coldest Possible Temperature in Zeer (K)"], labeldirections = [horizontal, vertical])

At a constant air temperature, the coldest possible temperature (i.e. the wet bulb temperature) increases as the relative humidity

(i.e. water in air) increases.

This makes sense because

 • If there is more water in the air, less water will evaporate from the wet sand between the two pots in the Zeer
 • and hence less latent heat will be removed

## Modelica custom component that reads the...

This MapleSim model contains a Modelica custom component that reads the CoolProp DLL. You'll need to change the path in the code to point to the location of the DLL on your computer.

ExternalCCodeCalls.msim

Samir

## @Thomas Richard Those techniques are no...

@Thomas Richard

• Those techniques are not appropriate for the typical home user (e.g. ISPs that block port 25, Windows OS etc)
• MailGun works also on the MapleCloud. I have Cloud applications that email results to the user (after the user has entered their email in a text area). Let me know if you want access.
