Quite often French curves are sold alongside "ship's curves" for drafting. My understanding is that all this sort of thing predates the kind of math that we'd nowadays associate with such curves or their construction.

I found this ["A History of Curves and Surfaces in SAGD" by Gerald Farin] link interesting. It suggests that ship builders used to keep the large curved ribs used in building ships hulls, as templates. This goes with the notion that the curves would be built by hand, and that it predates the mathematicalization of such curves. It's plausible then, that smaller French curve construction might also have originally been by-hand. That linked paper does make a hint that Pascal and Monge might have somehow been involved in the methodology, but doesn't give detail on that. The link goes on to talk about Bezier and others who subsequently established the math behind such processes.

acer

Is this (post, or parent thread) close enough that you can hammer it to fit?

Or do you just need the -c option of the `maple` script? With that option (or multiple instances of it!) you can initialize the session, etc. Eg.  'maple -c "assign(...)"

% maple -s -c "assign(x,4)"

    |\^/|     Maple 14 (SUN SPARC SOLARIS)
._|\|   |/|_. Copyright (c) Maplesoft, a division of Waterloo Maple Inc. 2010
 \  MAPLE  /  All rights reserved. Maple is a trademark of
 <____ ____>  Waterloo Maple Inc.
      |       Type ? for help.
> x;
                                       4

acer

You'd want to set the system to 'FPS', so that simplification of units results in units of feet for the dimension of length.

Apart from the three ways shown below, you could alternatively use the right-click context-sensitive menu action Units -> Simplify on the output.

> restart:

> Units:-UseSystem('FPS');

> Z := 5*Unit('ft'):
> simplify(Z^2);

                                      [  2]
                                   25 [ft ]

> restart:

> Units:-UseSystem('FPS');
> with(Units:-Standard):

> Z := 5*Unit('ft'):
> Z^2;

                                      [  2]
                                   25 [ft ]

> restart:

> Units:-UseSystem('FPS');

> Z := 5*Unit('ft'):
> Z^2:
> combine(%, 'units');

                                      [  2]
                                   25 [ft ]

acer

There is a predefined system of units whose base units for mass and length are gram and centimeter (see here). There are other ways to change the default units for any given dimension, but let us know if this is not adequate for you.

Maple will keep Pi as an exact quantity by default. One can use the `evalf` command to approximate it to floating-point. By default, Maple will use the `Digits` environment variable to control the working precision (see here). One can also set the display precision for Standard GUI output (see here). It's usually better to let Maple use at least its default setting of Digits=10 for computation (and to separately control only the final display) than it is to downgrade the computation precision to something as low as Digits=5 (which might allow too much roundoff error for you on more complicated expressions). Below I use `evalf[5]` on just the final result, as a programmatic way to adjust the final displayed float value.

> restart:

> with(Units:-Standard):
> Units:-UseSystem(CGS);

> wirediameter:=.40*Unit(inch):
> wirelength:=1000*Unit(ft):
> wirevolume:=(wirediameter/2)^2 * Pi * wirelength:
> wireweight:=61*Unit(lb):
> wiredensity:=evalf(wireweight/wirevolume):

> evalf[5](wiredensity);

                         [   g     ]
                  1.1197 [ ------- ]
                         [     3   ]
                         [   cm    ]

acer

Is this an attempt to phish for HD SNs associated with valid Maple licenses? (Isn't/wasn't HD SN an alternative to NIC SN for authentication?) Sorry if that sounds callous, but we live in troubled times.

acer

@turloughmack I apologize if I misinterpreted. The option price nomenclature part is technical jargon, and seems to obscure the fact that your difficulties seem to be with the coding aspects (which really are not specific to just that discipline). The jargon can obscure the question.

It might be better for legibility if you could use a notation that matched Maple's 1D notation, when posting the code as plaintext. For example, if your names are indexed then an entry for f might be f[i+1,j] and not f_i+1,j (which is what one might physically type, as 2D input). This is key, since even this interpretation might not be what you want. It seems that you might want the (i+1)th instance of a Vector f. In that case you could have a table of N Vectors f[i], with each member Vector having entries f[i][j], j=1..m. Or you might prefer to create an N by m Matrix f where each row represents a Vector and the indexing would be f[i,j].

It was pointed out in response to your earlier Question that square brackets are for list creation, and that you'd probably need round brackets as expression delimiters. But square brackets are still used above in the assignments of a[j], b[j], and c[j]. Is there a reason for that?

You've used `m` mostly, but in your setup of f[N] it appears that you really mean `M` (which is 10, as is N). Is that right? Is m supposed to be M, or vice versa?

Is this getting there?

restart:

a := j -> 1/2*(r-q)*j*Deltat - 1/2*sigma^2*j^2*Deltat:
b := j -> 1 + sigma^2*j^2*Deltat + r*Deltat:
c := j -> -1/2*(r-q)*j*Deltat - 1/2*sigma^2*j^2*Deltat:

r:= 0.05: Deltat:= T/N: DeltaS:=S/M: T:=0.4: q:=0: K:=1.1: S:=2: M:=10: N:=10:

thematrix := Matrix(M,M,scan=band[1,1],
            [[seq(a(j),j=1..M-1)],
             [seq(b(j),j=1..M)],
             [seq(c(j),j=1..M-1)]]):

f[N]:=Vector(M,(j)->max(K-j,DeltaS,0)):

thismatrix:=eval(thematrix,sigma=0.9):

for i from N to 2 by -1 do
 f[i-1] := LinearAlgebra:-LinearSolve(thismatrix,f[i]);
end do:

f[1];

invthismatrix:=thismatrix^(-1):
invthismatrix^9 . f[N];

It might be slightly more numerically stable to do the repeated LinearSolve, over MatrixInverse. But at this size problem any efficiency concerns and tweaks (re-using the LU decomposition, done just once) would make the code less clear for a negligible benefit I suspect.

Maybe the brute force way would do: find the x,y (err, Q1,Q2) values at the intersections. Then just draw eight curves instead of four. And have some of the eight get the dashed line style. See ?plot,option on chenging the line style.

Instead of creating all curves in a single plot structure right away, you could assign each to a name. Ie, P1:=plot3(....,Q1=-1..X, Q2=-1...1) where X is the Q1-coordinate of the intersection point. Analogously for the other curves, but some with the line style specified as an option. Then use plots:-display to show them all superimposed.

acer

What precisely do you mean by "prints itself"? Do you mean that calling it will produce as output the same result as would evaluating (or printing) it?

I have set interface(prettyprint=1) for these examples below.

> f:=proc() print(eval(procname)); end proc;
                 f := proc() print(eval(procname)) end proc;

> f();
proc() print(eval(procname)) end proc;

Note that the above does not work when the procedure is anonymous. But for that case, one can use the new (as of Maple 14, see here) `thisproc`,

> f:=proc() print(eval(procname)); end proc:

> %(); # NULL output, ie. it didn't succeed

> proc() print(eval(thisproc)); end proc;
proc() print(eval(thisproc)) end proc;

> %();
proc() print(eval(thisproc)) end proc;

It occurs to me that perhaps you instead mean that you want the result of calling `f` to simply be the name of f.

> f:=proc(x)
>    debugopts('callstack')[2];
> end proc:

> f();
                               f

> g:=proc() f(); end proc:
> g();
                               f

I found that callstack useful when coding a redefined version of (the protected) `userinfo` which would display results to a Text Component. This worked even when the code was run in a Maplet or other "hidden" facility, and it worked without having (access) to change or edit the original routine sources. The task was harder still -- to find out how the current parent procedure had been called. I'd meant to blog it...

Another way to get this simpler effect of printing only the current procedure's own name might be,

> f:=proc() op(1,''procname''); end proc:

> f();
                               f

Do either of those two interpretations of "prints itself" come close to your intended meaning?

acer

Hey Axel, I see you're still musing over that usenet post. One might easily get Maple to convert the following roots of that quintic to radicals, by just calling `solve` with its Explicit option.

> seq(cos(i*Pi/11),i in [1,3,5,7,9]);

           /1    \     /3    \     /5    \      /4    \      /2    \
        cos|-- Pi|, cos|-- Pi|, cos|-- Pi|, -cos|-- Pi|, -cos|-- Pi|
           \11   /     \11   /     \11   /      \11   /      \11   /

But these roots of that sextic look like they are going to be a little tougher... ;)

seq(cos(i*Pi/13),i in [1,3,5,7,9,11]);

    /1    \     /3    \     /5    \      /6    \      /4    \
 cos|-- Pi|, cos|-- Pi|, cos|-- Pi|, -cos|-- Pi|, -cos|-- Pi|,
    \13   /     \13   /     \13   /      \13   /      \13   /

       /2    \
   -cos|-- Pi|
       \13   /

acer

As 1D Maple notation input, your expression would need a star or a dot (* or .) between the bracketed terms in order to denote multiplication. For example, (a+b)*(a-b).

As 2D Math input, it would need either a star of a dot (typed in as * or .) for explicitly denoted multiplication or a space for implicitly denoted multiplication. For example .

Without any of these, the first set of bracketed terms get interpreted as (a sum of functions), and the entire expression as one big function application. The 1D and 2D parsers support a distributed function call syntax. Without the multiplication sign (or space for 2D input) the following are all parsed as function application:

> (sin+cos)(x);
                        sin(x) + cos(x)

> (sin+f)(x);
                         sin(x) + f(x)

> (f+g)(x-y);
                      f(x - y) + g(x - y)

> (a+b)(x-y);
                      a(x - y) + b(x - y)

> (a+b)(a-b);
                      a(a - b) + b(a - b)

The first term of even that last result is not the same as a*(a-b). No, it is `a` applied as a function, with argument a-b. There's no reason to prevent the parser from recognizing that an as-yet undefined operator `a` might be applied to the sum of names of other operators. Maple is so much more than just mere math.

Some people have expressed the opinion that Maple's relatively new implicit multiplication syntax (denoted by a space between terms, in 2D Math input) makes for visually confusing documents which obscure these syntax distinctions and lead inexperienced users to make this mistake more often.

acer

You should not be using the (officially) deprecated linalg package. You should use the newer LinearAlgebra package.

For transposition either use the LinearAlgebra:-Transpose command, or raise the Matrix or Vector to the %T power (eg. V^%T).

Remember that Maple is case-sensitive.

Also, use Matrix and Vector, not the deprecated matrix and vector commands.

You can extract a column using the shorter syntax E[1..-1,j]. So E[1..-1,5] would extract the 5th column of a Matrix E.

See ?rtable_indexing

acer

If this is an assignment for which you are supposed to explicitly demonstrate the solving method in action, then see dskoog's Answer.

If, on the other hand, you just want to apply a known method to solve your moderately sized numeric problem then you could use the LinearSolve command with the method=LU options. (Linear solving via LU dcomposition is pretty much just Gaussian elimination in disguise since the L factor provides a way to store the pivoting info. Generally, G.E. of an augmented system would get you half-way there, and you'd back-sub for the second stage. By doing LU and then both forward- and backward-sub'ing the whole task is done. The LinearSolve command would just do all those steps for you, internally.)

The quoted size of your problem makes me think that maybe you just want the system solved. Hence the method=LU and LinearSolve suggestion.

 X := LinearAlgebra:-LinearSolve(A, B, method=LU);

acer

Yes, use Re() and Im(), and not op().

And use I*Im(expr) if you want the imaginary component of expr, as opposed to the "imaginary part". The term "imaginary part" is being used to denote the real number b in a complex number a+b*I, say.

> Xi := sqrt(I);

                               1  (1/2)   1    (1/2)
                         Xi := - 2      + - I 2
                               2          2

> Bs := Matrix([[Re(Xi), I*Im(Xi)], [I*Im(Xi), Re(Xi)]]);

                             [ 1  (1/2)   1    (1/2)]
                             [ - 2        - I 2     ]
                             [ 2          2         ]
                       Bs := [                      ]
                             [1    (1/2)   1  (1/2) ]
                             [- I 2        - 2      ]
                             [2            2        ]

Use capitalized Matrix, not matrix.

acer

[deleted]

I misunderstood the request as being a question on how to expand the denominator. (I ought to read the Questions more carefully...)

acer

The ith entry of the column Vector B=A.x will be equal to add(A[i,j]*x[j], j=1..numcolsA). But for any fixed i the terms A[i,j], j=1..numcolsA are the entries of the ith row of A. The product A.x can be considered as a weighted linear combination of the columns (where the weights used for each of the j entries of any row are the x[j].

> A:=Matrix(2,3,symbol=a);

                           [a[1, 1]  a[1, 2]  a[1, 3]]
                      A := [                         ]
                           [a[2, 1]  a[2, 2]  a[2, 3]]

> x:=Vector(3, symbol=X);

                                      [X[1]]
                                      [    ]
                                 x := [X[2]]
                                      [    ]
                                      [X[3]]

> Vector(2, (i)->add(A[i,j]*x[j],j=1..3)); # Vector of weighted sums along rows

                [a[1, 1] X[1] + a[1, 2] X[2] + a[1, 3] X[3]]
                [                                          ]
                [a[2, 1] X[1] + a[2, 2] X[2] + a[2, 3] X[3]]

> add(A[1..2,j]*x[j], j=1..3); # weighted sum of the column Vectors

                [a[1, 1] X[1] + a[1, 2] X[2] + a[1, 3] X[3]]
                [                                          ]
                [a[2, 1] X[1] + a[2, 2] X[2] + a[2, 3] X[3]]

> A.x;

                [a[1, 1] X[1] + a[1, 2] X[2] + a[1, 3] X[3]]
                [                                          ]
                [a[2, 1] X[1] + a[2, 2] X[2] + a[2, 3] X[3]]

Looking at the last two results above: the Vector of weighted elementwise sums along rows is equal to the sum of weighted column Vectors.

acer
