I have a relatively complicated ODE that i am plotting. One of the variables in particular (B[2211], purple line in the graph) should under go an exponential-like decay to zero, but instead flies off into negative territory  (see graph below) despite having a very simple equation:

problem variable rate of change= -problem variable*constant +linear combination of variables that  are always posotive.

My intuition is that this is because i have somehow used the odeplot tool wrong - possibly due to a problem with stepsizes.

Here is a MWE i've made:

aa_problem_MWE.mw

Let say I want to generate polynomail with unknown coefficients of variable (x,y,z,t,s) of 3-th order (NOT RANDOM ONE!).

Hey!

The more "nodes, compartments, ..." I define the longer my formula (see below) gets. The formula posted below is written for a starting situation of 9 nodes (i,j,k,l,m,p,q,r,s). The problem that I have is that, besides running out of letters to chose from, the formula is getting to long and is not clear anymore (losing the overview). So I'm looking for a way to write it shorter, especially for the bold parts I assume there must be a better way.

B is a 9x9 matrix, n[0]:=1, N:=9

for i in n[0] do for j to N do for k to N do for l to N do for m to N do for o to N do for q to N do for r to N do for s to N do

if B(i, j) = 1 and B(j, k) = 1 and B(k, l) = 1 and B(l, m) = 1 and B(m, o) = 1 and B(o, q) = 1 and B(q, r) = 1 and B(r, s) = 1 and i <> j and i <> k and i <> l and i <> m and i <> o and i <> q and i <> r and i <> s and j <> k and j <> l and j <> m and j <> o and j <> q and j <> r and j <> s and k <> l and k <> m and k <> o and k <> q and k <> r and k <> s and l <> m and l <> o and l <> q and l <> r and l <> s and m <> o and m <> q and m <> r and m <> s and o <> q and o <> r and o <> s and q <> r and q <> s and r <> s

then P[loss, i, j, k, l, m, o, q, r, s] := P[loss, i, j, k, l, m, o, q, r]*P[fw, r, s]*P[suppr, i, j, k, l, m, o, q, r]*P[fo, s] else P[loss, i, j, k, l, m, o, q, r] := 0 end if; if P[loss, i, j, k, l, m, o, q, r] <> 0 then print(subs(I = i, J = j, K = k, L = l, M = m, O = o, Q = q, R = r, 'P[loss, I, J, K, L, M, O, Q, R]') = P[loss, i, j, k, l, m, o, q, r]) end if end do end do end do end do end do end do end do end do end do

I tried i<>j<>k<>l<>m<>o<>p<>q<>r<>s but that does't work

P.S.: Do you always have to specify something after ELSE using the IF loop? Actually I just don't want maple to do anything if the conditions are not met but since I then cannot print only the solutions I want (the ones for which the conditions are met) I always end up specifying something after else.

Thanks!!

This is about the recent implementation of tensor products of quantum state spaces in the Physics package, in connection with an exchange with the Physics of Information Lab of the University of Waterloo. As usual this development is available to everybody from the Maplesoft R&D Physics webpage. This is the last update for Maple 2017. The updates for Maple 2018, starting with this same material, will begin being distributed through the MapleCloud next week.

Download TensorProductDesign.mw


Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

Does any one know of a trick to make Maple solve this PDE using pdsolve?

restart;
pde:=diff(u(x,t),t)+diff(u(x,t),x)=0;
bc:=u(0,t)=0;
ic:=u(x,0)=x;
sol:=pdsolve({pde,ic,bc},u(x,t));

I have tried all HINTS and assumptions and Maple just returns () as solution.

Mathematica solve this as follows

ClearAll[u,x,t];
pde=D[u[x,t],t]+D[u[x,t],x]==0;
bc=u[0,t]==0;
ic=u[x,0]==x;
sol=DSolve[{pde,ic,bc},u[x,t],{x,t}]

Heavidside theta is basically a unit step function.

Download nn.mw


Download nn.mwnn.mw

Maple 2018.

I am surprised Maple pdsolve can't solve this basic heat PDE. it is heat PDE on bar, with left end boundary condition being time dependent is only difference from basic heat PDE's on a bar.

May be a Maple expert can find a work around? I tried all the HINTS I know about.

restart;
#infolevel[pdsolve] := 3:
pde:=diff(u(x,t),t)=diff(u(x,t),x$2);
bc:=u(0,t)=t,u(Pi,t)=0:
ic:=u(x,0)=0:
sol:=pdsolve([pde,bc,ic],u(x,t)) assuming t>0 and x>0;

I also hope this question of mine do not get deleted as well, like the question I posted last night asking why pdsolve ignores assumptions that showed number of examples, was deleted few hrs after I posted it.

If this question gets deleted, I will get the message that posts showing any problem in Maple software are not welcome here by Maplesoft and I will stop coming here.

Good day sirs,

         I am trying to solve this system of equations attached below, but got the following error message "The use of global variables in numerical ODE problems is deprecated, and will be removed in a future release".

       Anyone with useful informations please.

       Below is attached

how I can remove ROOTOF  from solution?

thanks.

root_of.mw

Hi, I've been doing a few small explore plots where the ranges for the parameters are something like [-1,1], but 0 is a special value which will often need to be set.  The slider, gauge components, ... are a bit fiddly to set with exactly zero using a mouse to drag the value.  Thought about a few different ways to do this

* Right click and set value from the component properties option - a bit fiddly for the user and the graph doesn't immediately update when OK'ed.

* Extra control with a tick to set a zero value (fiddly programming and possible confusing interpretation)

* Slider component and snaptoticks=true

Last option seems to be the easiest all round, but I was wondering why it is only the slider component that has a snaptoticks property - none of the other components seem to support it and a gauge would probably be a more natural component to use.

Thanks in advance

Dear sir I want to plot the graph where the lines are coincides maximize the graph in the same graph.  A sample graph i am attaching .some sample codes are here.

h:=z->1-(gamma2/2)*(1 + cos(2*(Pi/omicron1)*(z - d1 - omicron1))):
K1:=((4/h(z)^4)-(sin(Zeta1)/omega)-h(z)^2+Nb*h(z)^4):
kappa:=Int(K1,z=0..1):
omicron1:=0.2: omega:=10:d1:=0.2:Zeta1:=Pi/6:

plot( [seq(eval(kappa, Nb=j), j in [0.01,0.02,0.03])], gamma2=0.02..0.1);

Hi!

Consider, fixed an integer m>1, the mapping given by the following procedure:

G := proc (t) local k, C; C := NULL; C := t; for k from 2 to d do C := C, 1/2-(1/2)*cos(Pi*m^(k-1)*t) end do; return [C] end proc

Then, it can be proved that given x in the cube [0,1]^{d} there is t in [0,1] such that the norm of x-G(t) is less, or equal, than sqrt(d-1)/m. Indeed, dividing the cube [0,1]^{d} into m^{d-1} subcubes of side-length 1/m x ... x 1/m x 1, the point x belongs to some of these subcubes, say J. As, by the properties of the cosines function, the curve G(t) lies in J whenever t in certain subinterval of [0,1], the result follows.

In other words, computing all the solutions of the equation

1/2*(1-cos(Pi*m^(d-1)*t)) = x[d], (j-1)/m <= t and t <= j/m

for some of these solutions the desired t is obtained, where j is such that x₁ in [(j-1)/m,j/m] (x₁ is the first coordinate of the point x). However, for large values of m and d, the above equation have many solutions, I have tried find all of them and the process is extremely slow....Other way to find such a t can be the following: find a t satisfying the following system of inequalities

EQ := abs(t-x[1]) <= 1/m; for k from 2 to d do EQ := EQ, abs(1/2*(1-cos(Pi*m^(k-1)*t))-x[k]) <= 1/m end do

and then, a solution of this system is a such t. I do not know how to find, efficiently, a t such that of x-G(t) is less, or equal, than sqrt(d-1)/m   :(

Some idea?

Many thanks for your comments in advance.

This is using Maple 2018.

I noticed when solving Laplace PDE on disk, that no condition is needed to tell Maple if one is asking for solution inside the disk or outside. So how does Maple know which one it is?

It turned out Maple gives the same solution for the PDE outside as inside, which is wrong.

The solution to Laplace PDE inside a disk of radius 1 is

Which Maple gives correctly. But it also give the same above solution for outside the disk. The solution outside the disk should have r^(-n) and not r(n).  Like this

Basically Maple ignores assumption on `r`. This is what I tried

restart;
pde := (diff(r*(diff(u(r, theta), r)), r))/r+(diff(u(r, theta), theta, theta))/r^2 = 0:
bc := u(1, theta) = f(theta), u(r, -Pi) = u(r, Pi), (D[2](u))(r, -Pi) = (D[2](u))(r, Pi):
sol_inside:=pdsolve([pde, bc], u(r, theta), HINT = boundedseries) assuming r<1;

restart;
pde := (diff(r*(diff(u(r, theta), r)), r))/r+(diff(u(r, theta), theta, theta))/r^2 = 0:
bc := u(1, theta) = f(theta), u(r, -Pi) = u(r, Pi), (D[2](u))(r, -Pi) = (D[2](u))(r, Pi):
sol_outside:=pdsolve([pde, bc], u(r, theta)) assuming r>1;

Both the above gives the same answer.

How then does one solve the Laplace PDE outside the disk using Maple? And why is assumptions on "r" seems to be ignored in the above?

Hi,
I am new to using maple and was wondering if i could get some help with this problem...

I'm having problems with 2b)

pell := proc (d, K)

local y;

y := sqrt(d*x^2+1);

d := 2;

if y <= K then print*(x, y) end if

end proc


this is what i have come up with, feel like it is completely wrong though.

Any help would be much appreciated.

(ps. there is no Maple 2018 product to select, so I selected Maple 2017 from the menu).

The new UNTIL keyword added to Maple 2018 seems to me to be confusing and a useless addition to the Maple language.

First of all, using it in a DO loop, one does not use an closing END DO as normal. This makes it harder to use, since one is used to seeing an END DO to close each DO. They align physically better, which makes the code easier to read.

In addition, I can't think of anything that can't be done using current language constructs that needs this new keyword. Can someone?

Adding a whole new keyword to make one type maybe few less characters seems like  a bad language design. A language constructs should be orthogonal to each others for the language to remain simple and clean. Adding more keywords for the fun of it should be avoided if something can be written using exisiting language constructs.

n := 37:
do
  n := n + 1
until isprime(n);
n;

very confusing to read. It has no end do. At first, I did not see where the loop ends. And the above can be done in many other ways allready, one direct way could be

n := 37:
do
  n := n + 1;
  if isprime(n) then
     break;
  fi;
od;
n;

And it is more clear as well since the DO is aligned with the END DO and I find the logic clearer with no new keyword added. Another way could be

n:= 37:
found_prime := false:
while not found_prime do
   n:= n + 1;
   found_prime := isprime(n);
od:
n;

I am sure there are other ways to do this.

Could someone please show an example where UNTIL is really needed and will make the code much more clear that justifies adding it to the language?
