Solving DAEs in Maple

As I had mentioned in many posts, Maple cannot solve nonlinear DAEs. As of today (Maple 2015), given a system of index 1 DAE dy/dt = f(y,z); 0 = g(y,z), Maple “extends” g(y,z) to get dz/dt = g1(y,z). So, any given index 1 DAE is converted to a system of ODEs dy/dt = f, dz/dt = g1 with the constraint g = 0, before it solves. This is true for all the solvers in Maple despite the wrong claims in the help files. It is also true for MEBDFI, the FORTRAN implementation of which actually solves index 2 DAEs directly. In addition, the initial condition for the algebraic variable has to be consistent. The problem with using fsolve is that one cannot specify tolerance. Often times one has to solve DAEs at lower tolerances (1e-3 or 1e-4), not 1e-15. In addition, one cannot use compile =true for high efficiency.

The approach in Maple fails for many DAEs of practical interest. In addition, this can give wrong answers. For example, dy/dt = z, y^2+z^2-1=0, with y(0)=0 and z(0)=1 has a meaningful solution only from 0 to Pi/2, Maple’s dsolve/numeric will convert this to dy/dt = z and dz/dt = -y and integrate in time for ever. This is wrong as at t = Pi/2, the system becomes index 2 DAE and there is more than 1 acceptable solution.

We just recently got our paper accepted that helps Maple's dsolve and many ODE solvers in other languages handle DAEs directly. The approach is rather simple, the index 1 DAE is perturbed as dy/dt = f.S ; -mu.diff(g,t) = g. The switch function is a tanh function which is zero till t = tinit (initialization time). Mu is chosen to be a small number. In addition, lhs of the perturbed equation is simplified using approximate initial guesses as Maple cannot handle non-constant Mass matrix. The paper linked below gives below more details.

http://depts.washington.edu/maple/pubs/U_Apprach_FULL_DRAFT.pdf

Next, I discuss different examples (code attached).

Example 1: Simple DAE (one ODE and one AE), the proposed approach helps solve this system efficiently without knowing the exact initial condition.

Hint: The code is given with a semicolon at the end of the most of the statements for educational purposes for new users. Using semicolon after dsolve numeric in classic worksheet crashes the code (Maplesoft folks couldn’t fix this despite my request).

Example 2:

This is a nickel battery model (one ODE and one AE). This fails with many solvers unless exact IC is given. The proposed approach works well. In particular, stiff=true, implicit=true option is found to be very efficient. The code given in example 1 can be used to solve example 2 or any other DAEs by just entering ODEs, AEs, ICs in proper places.

Example 3:

This is a nonlinear implicit ODE (posted in Mapleprimes earlier by joha, (http://www.mapleprimes.com/questions/203096-Solving-Nonlinear-ODE#answer211682 ). This can be converted to index 1 DAE and solved using the proposed approach.

Example 4:

This example was posted earlier by me in Mapleprimes (http://www.mapleprimes.com/posts/149877-ODEs-PDEs-And-Special-Functions) . Don’t try to solve this in Maple using its dsolve numeric solver for N greater than 5 directly. The proposed approach can handle this well. Tuning the perturbation parameters and using compile =true will help in solving this system more efficiently.

Finally example 1 is solved for different perturbation parameters to show how one can arrive at convergence. Perhaps more sophisticated users and Maplesoft folks can enable this as automatically tuned parameters in dsolve/numeric.

Note:

This post should not be viewed as just being critical on Maple. I have wasted a lot of time assuming that Maple does what it claims in its help file. This post is to bring awareness about the difficulty in dealing with DAEs. It is perfectly fine to not have a DAE solver, but when literature or standard methods are cited/claimed, they should be implemented in proper form. I will forever remain a loyal Maple user as it has enabled me to learn different topics efficiently. Note that Maplesim can solve DAEs, but it is a pain to create a Maplesim model/project just for solving a DAE. Also, events is a pain with Maplesim. The reference to Mapleprimes links are missing in the article, but will be added before the final printing stage. The ability of Maple to find analytical Jacobian helps in developing many robust ODE and DAE solvers and I hope to post my own approaches that will solve more complicated systems.

I strongly encourage testing of the proposed approach and implementation for various educational/research purposes by various users. The proposed approach enables solving lithium-ion and other battery/electrochemical storage models accurately in a robust manner. A disclosure has been filed with the University of Washington to apply for a provisional patent for battery models and Battery Management System for transportation, storage and other applications because of the current commercial interest in this topic (for batteries). In particular, use of this single step avoids intialization issues/(no need to initialize separately) for parameter estimation, state estimation or optimal control of battery models.



Appendix A

Maple code for Examples 1-4 from "Extending Explicit and Linealry Implicit ODE Solvers for Index-1 DAEs", M. T. Lawder,

V. Ramadesigan, B. Suthar and V. R. Subramanian, Computers and Chemical Engineering, in press (2015).

Use y1, y2, etc. for all differential variables and z1, z2, etc. for all algebraic variables



Example 1

restart;

with(plots):

Enter all ODEs in eqode

eqode:=[diff(y1(t),t)=-y1(t)^2+z1(t)];

eqode := [diff(y1(t), t) = -y1(t)^2+z1(t)]

(1)

Enter all AEs in eqae

eqae:=[cos(y1(t))-z1(t)^0.5=0];

eqae := [cos(y1(t))-z1(t)^.5 = 0]

(2)

Enter all initial conditions for differential variables in icodes

icodes:=[y1(0)=0.25];

icodes := [y1(0) = .25]

(3)

Enter all intial conditions for algebraic variables in icaes

icaes:=[z1(0)=0.8];

icaes := [z1(0) = .8]

(4)

Enter parameters for perturbation value (mu), switch function (q and tint), and runtime (tf)

pars:=[mu=0.1,q=1000,tint=1,tf=5];

pars := [mu = .1, q = 1000, tint = 1, tf = 5]

(5)

Choose solving method (1 for explicit, 2 for implicit)

Xexplicit:=2;

Xexplicit := 2

(6)

Standard solver requires IC z(0)=0.938791 or else it will fail

solx:=dsolve({eqode[1],eqae[1],icodes[1],icaes[1]},numeric):

Error, (in dsolve/numeric/DAE/checkconstraints) the initial conditions do not satisfy the algebraic constraints
  error = .745e-1, tolerance = .559e-6, constraint = cos(y1(t))-z1(t)^.5000000000000000000000



ff:=subs(pars,1/2+1/2*tanh(q*(t-tint)));

ff := 1/2+(1/2)*tanh(1000*t-1000)

(7)

NODE:=nops(eqode);NAE:=nops(eqae);

NODE := 1

NAE := 1

(8)

for XX from 1 to NODE do
EQODE||XX:=lhs(eqode[XX])=rhs(eqode[XX])*ff;
end do;

EQODE1 := diff(y1(t), t) = (-y1(t)^2+z1(t))*(1/2+(1/2)*tanh(1000*t-1000))

(9)

for XX from 1 to NAE do
EQAE||XX:=subs(pars,-mu*(diff(rhs(eqae[XX])-lhs(eqae[XX]),t))=rhs(eqae[XX])-lhs(eqae[XX]));
end do;

EQAE1 := -.1*sin(y1(t))*(diff(y1(t), t))-0.5e-1*(diff(z1(t), t))/z1(t)^.5 = -cos(y1(t))+z1(t)^.5

(10)



Dvars1:={seq(diff(z||x(t),t)=D||x,x=1..NAE)};

Dvars1 := {diff(z1(t), t) = D1}

(11)

Dvars2:={seq(rhs(Dvars1[x])=lhs(Dvars1[x]),x=1..NAE)};

Dvars2 := {D1 = diff(z1(t), t)}

(12)

icsn:=seq(subs(y||x(0)=y||x(t),icodes[x]),x=1..NODE),seq(subs(z||x(0)=z||x(t),icaes[x]),x=1..NAE);

icsn := y1(t) = .25, z1(t) = .8

(13)

for j from 1 to NAE do

EQAEX||j:=subs(Dvars1,eqode,icsn,Dvars2,lhs(EQAE||j))=rhs(EQAE||j);

end do:

Sys:={seq(EQODE||x,x=1..NODE),seq(EQAEX||x,x=1..NAE),seq(icodes[x],x=1..NODE),seq(icaes[x],x=1..NAE)};

Sys := {-0.1824604200e-1-0.5590169945e-1*(diff(z1(t), t)) = -cos(y1(t))+z1(t)^.5, y1(0) = .25, z1(0) = .8, diff(y1(t), t) = (-y1(t)^2+z1(t))*(1/2+(1/2)*tanh(1000*t-1000))}

(14)

if Xexplicit=1 then

sol:=dsolve(Sys,numeric):

else

sol:=dsolve(Sys,numeric,stiff=true,implicit=true):
end if:



for XX from 1 to NODE do
a||XX:=odeplot(sol,[t,y||XX(t)],0..subs(pars,tf),color=red);
end do:

for XX from NODE+1 to NODE+NAE do
a||XX:=odeplot(sol,[t,z||(XX-NODE)(t)],0..subs(pars,tf),color=blue);
end do:

display(seq(a||x,x=1..NODE+NAE),axes=boxed);



End Example 1



Example 2

restart;

with(plots):

eq1:=diff(y1(t),t)=j1*W/F/rho/V;

eq1 := diff(y1(t), t) = j1*W/(F*rho*V)

(15)

eq2:=j1+j2=iapp;

eq2 := j1+j2 = iapp

(16)

j1:=io1*(2*(1-y1(t))*exp((0.5*F/R/T)*(z1(t)-phi1))-2*y1(t)*exp((-0.5*F/R/T)*(z1(t)-phi1)));

j1 := io1*(2*(1-y1(t))*exp(.5*F*(z1(t)-phi1)/(R*T))-2*y1(t)*exp(-.5*F*(z1(t)-phi1)/(R*T)))

(17)

j2:=io2*(exp((F/R/T)*(z1(t)-phi2))-exp((-F/R/T)*(z1(t)-phi2)));

j2 := io2*(exp(F*(z1(t)-phi2)/(R*T))-exp(-F*(z1(t)-phi2)/(R*T)))

(18)

params:={F=96487,R=8.314,T=298.15,phi1=0.420,phi2=0.303,W=92.7,V=1e-5,io1=1e-4,io2=1e-10,iapp=1e-5,rho=3.4};

params := {F = 96487, R = 8.314, T = 298.15, V = 0.1e-4, W = 92.7, io1 = 0.1e-3, io2 = 0.1e-9, rho = 3.4, iapp = 0.1e-4, phi1 = .420, phi2 = .303}

(19)

eqode:=[subs(params,eq1)];

eqode := [diff(y1(t), t) = 0.5651477584e-2*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)-0.5651477584e-2*y1(t)*exp(-19.46229155*z1(t)+8.174162450)]

(20)

eqae:=[subs(params,eq2)];

eqae := [0.2e-3*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)-0.2e-3*y1(t)*exp(-19.46229155*z1(t)+8.174162450)+0.1e-9*exp(38.92458310*z1(t)-11.79414868)-0.1e-9*exp(-38.92458310*z1(t)+11.79414868) = 0.1e-4]

(21)

icodes:=[y1(0)=0.05];

icodes := [y1(0) = 0.5e-1]

(22)

icaes:=[z1(0)=0.7];

icaes := [z1(0) = .7]

(23)

solx:=dsolve({eqode[1],eqae[1],icodes[1],icaes[1]},type=numeric):

Error, (in dsolve/numeric/DAE/checkconstraints) the initial conditions do not satisfy the algebraic constraints
  error = .447e9, tolerance = .880e4, constraint = -2000000*(-1+y1(t))*exp(19.46229155000000000000*z1(t)-8.174162450000000000000)-2000000*y1(t)*exp(-19.46229155000000000000*z1(t)+8.174162450000000000000)+exp(38.92458310000000000000*z1(t)-11.79414868000000000000)-exp(-38.92458310000000000000*z1(t)+11.79414868000000000000)-100000



pars:=[mu=0.00001,q=1000,tint=1,tf=5001];

pars := [mu = 0.1e-4, q = 1000, tint = 1, tf = 5001]

(24)

Xexplicit:=2;

Xexplicit := 2

(25)

ff:=subs(pars,1/2+1/2*tanh(q*(t-tint)));

ff := 1/2+(1/2)*tanh(1000*t-1000)

(26)

NODE:=nops(eqode):NAE:=nops(eqae);

NAE := 1

(27)

for XX from 1 to NODE do
EQODE||XX:=lhs(eqode[XX])=rhs(eqode[XX])*ff:
end do;

EQODE1 := diff(y1(t), t) = (0.5651477584e-2*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)-0.5651477584e-2*y1(t)*exp(-19.46229155*z1(t)+8.174162450))*(1/2+(1/2)*tanh(1000*t-1000))

(28)

for XX from 1 to NAE do
EQAE||XX:=subs(pars,-mu*(diff(rhs(eqae[XX])-lhs(eqae[XX]),t))=rhs(eqae[XX])-lhs(eqae[XX]));
end do;

EQAE1 := -0.2e-8*(diff(y1(t), t))*exp(19.46229155*z1(t)-8.174162450)+0.3892458310e-7*(1-y1(t))*(diff(z1(t), t))*exp(19.46229155*z1(t)-8.174162450)-0.2e-8*(diff(y1(t), t))*exp(-19.46229155*z1(t)+8.174162450)+0.3892458310e-7*y1(t)*(diff(z1(t), t))*exp(-19.46229155*z1(t)+8.174162450)+0.3892458310e-13*(diff(z1(t), t))*exp(38.92458310*z1(t)-11.79414868)+0.3892458310e-13*(diff(z1(t), t))*exp(-38.92458310*z1(t)+11.79414868) = 0.1e-4-0.2e-3*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)+0.2e-3*y1(t)*exp(-19.46229155*z1(t)+8.174162450)-0.1e-9*exp(38.92458310*z1(t)-11.79414868)+0.1e-9*exp(-38.92458310*z1(t)+11.79414868)

(29)

Dvars1:={seq(diff(z||x(t),t)=D||x,x=1..NAE)};

Dvars1 := {diff(z1(t), t) = D1}

(30)

Dvars2:={seq(rhs(Dvars1[x])=lhs(Dvars1[x]),x=1..NAE)};

Dvars2 := {D1 = diff(z1(t), t)}

(31)

icsn:=seq(subs(y||x(0)=y||x(t),icodes[x]),x=1..NODE),seq(subs(z||x(0)=z||x(t),icaes[x]),x=1..NAE);

icsn := y1(t) = 0.5e-1, z1(t) = .7

(32)

for j from 1 to NAE do

EQAEX||j:=subs(Dvars1,eqode,icsn,Dvars2,lhs(EQAE||j))=rhs(EQAE||j);

end do;

EQAEX1 := -0.2e-8*(0.5368903705e-2*exp(5.449441630)-0.2825738792e-3*exp(-5.449441630))*exp(5.449441630)+0.3697835394e-7*(diff(z1(t), t))*exp(5.449441630)-0.2e-8*(0.5368903705e-2*exp(5.449441630)-0.2825738792e-3*exp(-5.449441630))*exp(-5.449441630)+0.1946229155e-8*(diff(z1(t), t))*exp(-5.449441630)+0.3892458310e-13*(diff(z1(t), t))*exp(15.45305949)+0.3892458310e-13*(diff(z1(t), t))*exp(-15.45305949) = 0.1e-4-0.2e-3*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)+0.2e-3*y1(t)*exp(-19.46229155*z1(t)+8.174162450)-0.1e-9*exp(38.92458310*z1(t)-11.79414868)+0.1e-9*exp(-38.92458310*z1(t)+11.79414868)

(33)

Sys:={seq(EQODE||x,x=1..NODE),seq(EQAEX||x,x=1..NAE),seq(icodes[x],x=1..NODE),seq(icaes[x],x=1..NAE)};

Sys := {-0.5810962488e-6+0.8802389238e-5*(diff(z1(t), t)) = 0.1e-4-0.2e-3*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)+0.2e-3*y1(t)*exp(-19.46229155*z1(t)+8.174162450)-0.1e-9*exp(38.92458310*z1(t)-11.79414868)+0.1e-9*exp(-38.92458310*z1(t)+11.79414868), y1(0) = 0.5e-1, z1(0) = .7, diff(y1(t), t) = (0.5651477584e-2*(1-y1(t))*exp(19.46229155*z1(t)-8.174162450)-0.5651477584e-2*y1(t)*exp(-19.46229155*z1(t)+8.174162450))*(1/2+(1/2)*tanh(1000*t-1000))}

(34)

if Xexplicit=1 then

sol:=dsolve(Sys,numeric,maxfun=0):

else

sol:=dsolve(Sys,numeric,stiff=true,implicit=true,maxfun=0):

end if:



for XX from 1 to NODE do
a||XX:=odeplot(sol,[t,y||XX(t)],0..subs(pars,tf),color=red);
end do:

for XX from NODE+1 to NODE+NAE do
a||XX:=odeplot(sol,[t,z||(XX-NODE)(t)],0..subs(pars,tf),color=blue);
end do:

b1:=odeplot(sol,[t,y1(t)],0..1,color=red):
b2:=odeplot(sol,[t,z1(t)],0..1,color=blue):

display(b1,b2,axes=boxed);



display(seq(a||x,x=1..NODE+NAE),axes=boxed);



End Example 2



Example 3

restart;

with(plots):

eq1:=diff(y1(t),t)^2+diff(y1(t),t)*(y1(t)+1)+y1(t)=cos(diff(y1(t),t));

eq1 := (diff(y1(t), t))^2+(diff(y1(t), t))*(y1(t)+1)+y1(t) = cos(diff(y1(t), t))

(35)

solx:=dsolve({eq1,y1(0)=0},numeric):

Error, (in dsolve/numeric/make_proc) Could not convert to an explicit first order system due to 'RootOf'



eqode:=[diff(y1(t),t)=z1(t)];

eqode := [diff(y1(t), t) = z1(t)]

(36)

eqae:=[subs(eqode,eq1)];

eqae := [z1(t)^2+z1(t)*(y1(t)+1)+y1(t) = cos(z1(t))]

(37)

icodes:=[y1(0)=0.0];

icodes := [y1(0) = 0.]

(38)

icaes:=[z1(0)=0.0];

icaes := [z1(0) = 0.]

(39)

pars:=[mu=0.1,q=1000,tint=1,tf=4];

pars := [mu = .1, q = 1000, tint = 1, tf = 4]

(40)

Xexplicit:=2;

Xexplicit := 2

(41)

ff:=subs(pars,1/2+1/2*tanh(q*(t-tint)));

ff := 1/2+(1/2)*tanh(1000*t-1000)

(42)

NODE:=nops(eqode);NAE:=nops(eqae);

NODE := 1

NAE := 1

(43)

for XX from 1 to NODE do
EQODE||XX:=lhs(eqode[XX])=rhs(eqode[XX])*ff:
end do;

EQODE1 := diff(y1(t), t) = z1(t)*(1/2+(1/2)*tanh(1000*t-1000))

(44)

for XX from 1 to NAE do
EQAE||XX:=subs(pars,-mu*(diff(rhs(eqae[XX])-lhs(eqae[XX]),t))=rhs(eqae[XX])-lhs(eqae[XX]));
end do;

EQAE1 := .1*sin(z1(t))*(diff(z1(t), t))+.2*z1(t)*(diff(z1(t), t))+.1*(diff(z1(t), t))*(y1(t)+1)+.1*z1(t)*(diff(y1(t), t))+.1*(diff(y1(t), t)) = cos(z1(t))-z1(t)^2-z1(t)*(y1(t)+1)-y1(t)

(45)



Dvars1:={seq(diff(z||x(t),t)=D||x,x=1..NAE)};

Dvars1 := {diff(z1(t), t) = D1}

(46)

Dvars2:={seq(rhs(Dvars1[x])=lhs(Dvars1[x]),x=1..NAE)};

Dvars2 := {D1 = diff(z1(t), t)}

(47)

icsn:=seq(subs(y||x(0)=y||x(t),icodes[x]),x=1..NODE),seq(subs(z||x(0)=z||x(t),icaes[x]),x=1..NAE);

icsn := y1(t) = 0., z1(t) = 0.

(48)

for j from 1 to NAE do

EQAEX||j:=subs(Dvars1,eqode,icsn,Dvars2,lhs(EQAE||j))=rhs(EQAE||j);

end do;

EQAEX1 := .1*sin(0.)*(diff(z1(t), t))+.1*(diff(z1(t), t)) = cos(z1(t))-z1(t)^2-z1(t)*(y1(t)+1)-y1(t)

(49)

Sys:={seq(EQODE||x,x=1..NODE),seq(EQAEX||x,x=1..NAE),seq(icodes[x],x=1..NODE),seq(icaes[x],x=1..NAE)};

Sys := {.1*(diff(z1(t), t)) = cos(z1(t))-z1(t)^2-z1(t)*(y1(t)+1)-y1(t), y1(0) = 0., z1(0) = 0., diff(y1(t), t) = z1(t)*(1/2+(1/2)*tanh(1000*t-1000))}

(50)

if Xexplicit=1 then

sol:=dsolve(Sys,numeric):

else

sol:=dsolve(Sys,numeric,stiff=true,implicit=true):

end if:



for XX from 1 to NODE do
a||XX:=odeplot(sol,[t,y||XX(t)],0..subs(pars,tf),color=red);
end do:

for XX from NODE+1 to NODE+NAE do
a||XX:=odeplot(sol,[t,z||(XX-NODE)(t)],0..subs(pars,tf),color=blue);
end do:

display(seq(a||x,x=1..NODE+NAE),axes=boxed);



End Example 3



Example 4

restart;

with(plots):

N:=11:h:=1/(N+1):

for i from 2 to N+1 do eq1[i]:=diff(y||i(t),t)=(y||(i+1)(t)-2*y||i(t)+y||(i-1)(t))/h^2-y||i(t)*(1+z||i(t));od:

for i from 2 to N+1 do eq2[i]:=0=(z||(i+1)(t)-2*z||i(t)+z||(i-1)(t))/h^2-(1-y||i(t)^2)*(exp(-z||i(t)));od:

eq1[1]:=(3*y1(t)-4*y2(t)+y3(t))/(2*h)=0: eq1[N+2]:=y||(N+2)(t)-1=0:

eq2[1]:=(3*z1(t)-4*z2(t)+1*z3(t))/(2*h)=0: eq2[N+2]:=z||(N+2)(t)=0:

eq1[1]:=subs(y1(t)=z||(N+3)(t),eq1[1]):

eq1[N+2]:=subs(y||(N+2)(t)=z||(N+4)(t),eq1[N+2]):

eqode:=[seq(subs(y1(t)=z||(N+3)(t),y||(N+2)(t)=z||(N+4)(t),eq1[i]),i=2..N+1)]:

eqae:=[eq1[1],eq1[N+2],seq(eq2[i],i=1..N+2)]:

icodes:=[seq(y||j(0)=1,j=2..N+1)]:

icaes:=[seq(z||j(0)=0,j=1..N+2),z||(N+3)(0)=1,z||(N+4)(0)=1]:

pars:=[mu=0.00001,q=1000,tint=1,tf=2]:

Xexplicit:=2:

ff:=subs(pars,1/2+1/2*tanh(q*(t-tint))):

NODE:=nops(eqode):NAE:=nops(eqae):

for XX from 1 to NODE do

EQODE||XX:=lhs(eqode[XX])=rhs(eqode[XX])*ff: end do:

for XX from 1 to NAE do

EQAE||XX:=subs(pars,-mu*(diff(rhs(eqae[XX])-lhs(eqae[XX]),t))=rhs(eqae[XX])-lhs(eqae[XX])); end do:

Dvars1:={seq(diff(z||x(t),t)=D||x,x=1..NAE)}:

Dvars2:={seq(rhs(Dvars1[x])=lhs(Dvars1[x]),x=1..NAE)}:

icsn:=seq(subs(y||x(0)=y||x(t),icodes[x]),x=1..NODE),seq(subs(z||x(0)=z||x(t),icaes[x]),x=1..NAE):

for j from 1 to NAE do

EQAEX||j:=subs(Dvars1,eqode,icsn,Dvars2,lhs(EQAE||j))=rhs(EQAE||j):

end do:

Sys:={seq(EQODE||x,x=1..NODE),seq(EQAEX||x,x=1..NAE),seq(icodes[x],x=1..NODE),seq(icaes[x],x=1..NAE)}:

if Xexplicit=1 then

sol:=dsolve(Sys,numeric,maxfun=0):

else

sol:=dsolve(Sys,numeric,stiff=true,implicit=true,maxfun=0):

end if:



for XX from 1 to NODE do

a||XX:=odeplot(sol,[t,y||(XX+1)(t)],1..subs(pars,tf),color=red): end do:

for XX from NODE+1 to NODE+NAE do

a||XX:=odeplot(sol,[t,z||(XX-NODE)(t)],1..subs(pars,tf),color=blue): end do:

display(seq(a||x,x=1..NODE),a||(NODE+NAE-1),a||(NODE+NAE),axes=boxed);



End of Example 4



Sometimes the parameters of the switch function and perturbation need to be tuned to obtain propoer convergence. Below is Example 1 shown for several cases using the 'parameters' option in Maple's dsolve to compare how tuning parameters affects the solution

restart:

with(plots):

eqode:=[diff(y1(t),t)=-y1(t)^2+z1(t)]: eqae:=[cos(y1(t))-z1(t)^0.5=0]:

icodes:=[y1(0)=0.25]: icaes:=[z1(0)=0.8]:

pars:=[tf=5]:

Xexplicit:=2;

Xexplicit := 2

(51)

ff:=subs(pars,1/2+1/2*tanh(q*(t-tint))):

NODE:=nops(eqode):NAE:=nops(eqae):

for XX from 1 to NODE do
EQODE||XX:=lhs(eqode[XX])=rhs(eqode[XX])*ff:
end do:

for XX from 1 to NAE do
EQAE||XX:=subs(pars,-mu*(diff(rhs(eqae[XX])-lhs(eqae[XX]),t))=rhs(eqae[XX])-lhs(eqae[XX]));
end do:



Dvars1:={seq(diff(z||x(t),t)=D||x,x=1..NAE)}:

Dvars2:={seq(rhs(Dvars1[x])=lhs(Dvars1[x]),x=1..NAE)}:

icsn:=seq(subs(y||x(0)=y||x(t),icodes[x]),x=1..NODE),seq(subs(z||x(0)=z||x(t),icaes[x]),x=1..NAE):

for j from 1 to NAE do

EQAEX||j:=subs(Dvars1,eqode,icsn,Dvars2,lhs(EQAE||j))=rhs(EQAE||j):

end do:

Sys:={seq(EQODE||x,x=1..NODE),seq(EQAEX||x,x=1..NAE),seq(icodes[x],x=1..NODE),seq(icaes[x],x=1..NAE)}:

if Xexplicit=1 then

sol:=dsolve(Sys,numeric,'parameters'=[mu,q,tint],maxfun=0):

else

sol:=dsolve(Sys,numeric,'parameters'=[mu,q,tint],stiff=true,implicit=true):

end if:



sol('parameters'=[0.1,1000,1]):

plot1:=odeplot(sol,[t-1,y1(t)],0..4,color=red):
plot2:=odeplot(sol,[t-1,z1(t)],0..4,color=blue):

sol('parameters'=[0.001,10,1]):

plot3:=odeplot(sol,[t-1,y1(t)],0..4,color=red,linestyle=dot):
plot4:=odeplot(sol,[t-1,z1(t)],0..4,color=blue,linestyle=dot):

display(plot1,plot2,plot3,plot4,axes=boxed);



In general, one has to decrease mu, and increase q and tint until convergence (example at t=3)

sol('parameters'=[0.001,10,1]):sol(3+1);

[t = 4., y1(t) = .738587929442734, z1(t) = .546472878850096]

(52)

sol('parameters'=[0.0001,100,10]):sol(3+10);

[t = 13., y1(t) = .738684397167344, z1(t) = .546618936273638]

(53)

sol('parameters'=[0.00001,1000,20]):sol(3+20);

[t = 23., y1(t) = .738694113087217, z1(t) = .546633473784526]

(54)



The results have converged to 4 digits after the decimal. Of course, absolute and relative tolerances of the solvers can be modified if needed



Download SolvingDAEsinMaple.mws

Last month, we received a very kind note from a recipient of one of our sponsorships. Maplesoft sponsors several academic and commercial events throughout the year, providing free copies of Maple or MapleSim to lucky attendees. Audrey was one of the winners of the Elgin Community College Calculus Contest, where she won a copy of Maple. Here’s what she had to say:

Thank you so much for the Maple license.  I have become familiar with Maple during the last school year.  At first the commands were like Chinese to me and I had a rough time getting anything done, but once I made a connection between the commands and what they were doing it was a lot easier.  Even without former knowledge of computer programing, the commands are increasingly intuitive.  Maple has been a huge help to me doing my homework and projects, and even as I was studying for the competition it was useful for checking my answers.  Another reason that I love Maple is that it provides visuals for the difficult concepts we learned in class, such as shell method in Calc II and mixed partial derivatives in Calc III.  I enjoy math, but I thank that Maple has enriched my experience along the way.

Thank you again for your generous gift,

~Audrey~

It’s always nice to hear how students and professionals alike are succeeding with the help of Maple. If you’d like to share your experience, please send an email to customerservice@maplesoft.com or post it here on MaplePrimes.

On a related post here, I have posted some screen shots for fun. Today is a special day for me in particular, because I passed my PhD viva with minor corrections! If you look colsely on the date, by coincidence, it was TWO years ago exactly. So I feel like I maybe 'update' the old post with a bit more, to make it V2.



So here comes the new screent shots: (Bear with me for now, I will post some actual content about how I feel when using Maple later.)

Alright, enough with the screent shots. If you click to see the big picture, you would notice that I have managed to get a complete sets of Maple versions from Maple V to Maple 2015!



===============================================

I am originally from Shanghai and I have always done well in Maths and science. I first heard about Maple in 2004 from a Maths teacher. He introduced me to this software. I played just a couple of times with Maple 6 on his computer, to get a first impression. At that time, all I could say was, hmmm insteresting.



In 2006, I went to UK for a foundation course. That was the first time I was actually taught how to use Maple 9.5. So I had access to it on the university computers. I discovered a lot about Maple and used it for ALL my Maths homeworks. Yes, I am lazy. I hope that Maple can do everything!



Then I got fascinated with Maple. Unfortunately, Maple was not taught in the undergraduate course. But there are materials for self-learning. By that time, I had become quite good with most of the contents in those materials. So I went look for other things to try. I went to ask my foundation course classmates, to see if they have anything on Maple and if they needed the help. One of them was at Imperial College and the questions were a bit chanlleging (finally!). That was the time I first met MaplePrimes! Hello, how have you been?



After that I have never stopped using Maple or Maple Primes. I may have been quite on the forum, but I was there. My PhD research rely hugely on the ability to compute the symbolic rank of certain matrices as well as the ability to simplifiying complicated expressions using siderules.



I do not want to talk too much about the technical details when using Maple. But I do

THANK Maple and it creators, developers and all relavent staff around the globe.

THANK Maple Primes and all its users. Some users have been particulary helpful!



Lastly, I dont have any other words to say other than this:

It's been really fun and enjoyable. Thanks!





We’re trying out something new with our webinars and are hosting our first ever live streaming webinar. Broadcast in real time, and featuring Jonny Zivku, our Maple T.A. Product Manager, this will be your chance to see the face behind the voice, as well as learn more about how academic institutions around the world are using Maple T.A. We hope you can join us.

Here are the full details:

Transforming Testing and Assessment with Maple T.A.

In this webinar, you will learn how Maplesoft's testing and assessment system, Maple T.A., is being used to improve learning, save money, reduce drop-out rates, and increase student satisfaction at academic institutions around the world.

The following Maple T.A. case studies will be presented:

  • The University of Waterloo saved $100,000/year on their grading budget
  • At the Amsterdam University of Applied Science, student pass rates went up approximately 20% within one year
  • The University of Canterbury continued to offer their full academic program after an earthquake damaged classrooms
  • At the University of Guelph, drop-out rates were reduced by more than 10%
  • ...And more!

All attendees of this webinar will be sent a complimentary copy of the Maplesoft magazine Transforming Testing and Assessment.

To join us for the live streaming webinar, please click here to register.



     Maple is seriously used in my article Approximation of subharmonic functions in the half-plane by the logarithm of the modulus of an analytic function. Math. Notes 78, No 4, 447-455 in two places. The purpose of this post is to present these applications.                                                                                                 First, I needed to prove the elementary inequality (related to the properties of the minimal harmonic majorant of the function 1/Im z in a certain strip)                                                                                                    2R+sqrt(R)-R(R+sqrt(R))y - 1/y   1/4                                                                                                  for    y ≥ 1/(R+sqrt(R)) and  y ≤ 1/R, the parameter R is greater than or equal to 1.   The artless attemt
restart; `assuming`([maximize(2*R+sqrt(R)-R*(R+sqrt(R))*y-1/y, y = 1/(R+sqrt(R)) .. 1/R)], [R >= 1])

maximize(2*R+R^(1/2)-R*(R+R^(1/2))*y-1/y, y = 1/(R+R^(1/2)) .. 1/R)

(1)

fails. The second (and successful) try consists in the use of optimizers:

F := proc (R) options operator, arrow; evalf(maximize(2*R+sqrt(R)-R*(R+sqrt(R))*y-1/y, y = 1/(R+sqrt(R)) .. 1/R)) end proc:

F(1)

.171572876

(2)



Optimization:-Minimize('F(R)', {R >= 1})

[.171572875253809986, [R = HFloat(1.0)]]

(3)

To be sure ,
DirectSearch:-Search(proc (R) options operator, arrow; F(R) end proc, {R >= 1})
;

[.171572875745665, Vector(1, {(1) = 1.0000000195752754}, datatype = float[8]), 11]

(4)

Because 0.17
"158 < 0.25, the inequality is  proved.   "
Now we establish this  by the use of the derivative.

solve(diff(2*R+sqrt(R)-R*(R+sqrt(R))*y-1/y, y) = 0, y, explicit)

1/(R^(3/2)+R^2)^(1/2), -1/(R^(3/2)+R^2)^(1/2)

(5)

maximize(1/sqrt(R^(3/2)+R^2)-1/(R+sqrt(R)), R = 1 .. infinity, location)

(1/2)*2^(1/2)-1/2, {[{R = 1}, (1/2)*2^(1/2)-1/2]}

(6)

minimize(eval(2*R+sqrt(R)-R*(R+sqrt(R))*y-1/y, y = 1/sqrt(R^(3/2)+R^2)), R = 1 .. infinity, location)

3-2*2^(1/2), {[{R = 1}, 3-2*2^(1/2)]}

(7)

evalf(3-2*sqrt(2))

.171572876

(8)

The second use of Maple was the calculation of the asymptotics of the following integral (This is the double integral of the Laplacian of 1/Im z over the domain {z: |z-iR/2| < R/2} \ {z: |z| ≤ 1}.). That place is the key point of the proof. Its direct calculation in the polar coordinates fails.

`assuming`([(int(int(2/(r^2*sin(phi)^3), r = 1 .. R*sin(phi)), phi = arcsin(1/R) .. Pi-arcsin(1/R)))/(2*Pi)], [R >= 1])

(1/2)*(int(int(2/(r^2*sin(phi)^3), r = 1 .. R*sin(phi)), phi = arcsin(1/R) .. Pi-arcsin(1/R)))/Pi

(9)

In order to overcome the difficulty, we find the inner integral

`assuming`([(int(2/(r^2*sin(phi)^3), r = 1 .. R*sin(phi)))/(2*Pi)], [R*sin(phi) >= 1])

(R*sin(phi)-1)/(sin(phi)^4*R*Pi)

(10)

and then we find the outer integral. Because
`assuming`([int((R*sin(phi)-1)/(sin(phi)^4*R*Pi), phi = arcsin(1/R) .. Pi-arcsin(1/R))], [R >= 1])

int((R*sin(phi)-1)/(sin(phi)^4*R*Pi), phi = arcsin(1/R) .. Pi-arcsin(1/R))

(11)

is not successful, we find the indefinite integral

J := int((R*sin(phi)-1)/(sin(phi)^4*R*Pi), phi)

-(1/2)*cos(phi)/(Pi*sin(phi)^2)+(1/2)*ln(csc(phi)-cot(phi))/Pi+(1/3)*cos(phi)/(R*Pi*sin(phi)^3)+(2/3)*cos(phi)/(R*Pi*sin(phi))

(12)

We verify that  the domain of the antiderivative includes the range of the integration.
plot(-cos(phi)/sin(phi)^2+ln(csc(phi)-cot(phi)), phi = 0 .. Pi)



plot((2/3)*cos(phi)/sin(phi)^3+(4/3)*cos(phi)/sin(phi), phi = 0 .. Pi)



    That's all right. By the Newton-Leibnitz formula,

``
eval(J, phi = Pi-arcsin(1/R))-(eval(J, phi = arcsin(1/R)));

(1/3)*(1-1/R^2)^(1/2)*R^2/Pi+(1/2)*ln((1-1/R^2)^(1/2)*R+R)/Pi-(4/3)*(1-1/R^2)^(1/2)/Pi-(1/2)*ln(R-(1-1/R^2)^(1/2)*R)/Pi

(13)

Finally, the*asymptotics*is found by

asympt(eval(J, phi = Pi-arcsin(1/R))-(eval(J, phi = arcsin(1/R))), R, 3)

(1/3)*R^2/Pi-(3/2)/Pi+(1/2)*(ln(2)+ln(R))/Pi-(1/2)*(-ln(2)-ln(R))/Pi+O(1/R^2)

(14)

      It should be noted that a somewhat different expression is written in the article. My inaccuracy, as far as I remember it, consisted in the integration over the whole disk {z: |z-iR/2| < R/2} instead of {z: |z-iR/2| < R/2} \ {z: |z| ≤ 1}. Because only the form of the asymptotics const*R^2 + remainder is used in the article, the exact value of this non-zero constant is of no importance.

       It would be nice if somebody else presents similar examples here or elsewhere.



Download Discovery_with_Maple.mw

Math powers the world. From tracking the spread of an epidemic to designing a new rocket engine, mathematical equations allow us to understand a challenge and formulate an approach to solving it. Everywhere around us, math is ubiquitous; an equation determines how your thermostat controls your home furnace; a mathematical algorithm is used to encode the signal from your cell phone. More than ever, we rely on mathematics to make our lives better. And continually, our mathematical techniques get more refined as we solve more and more complex problems.

Greetings to all.

I am writing to alert MaplePrimes users to a Maple package that makes an remarkable contribution to combinatorics and really ought to be part of your discrete math / symbolic combinatorics class if you teach one. The combstruct package was developed at INRIA in Paris, France, by the algorithmics research team of P. Flajolet during the mid 1990s. This software package features a parser for grammars involving combinatorial operators such as sequence, set or multiset and it can derive functional equations from the grammar as well as exponential and ordinary generating functions for labeled and unlabeled enumeration. Coefficients of these generating functions can be computed. All of it easy to use and very powerful. If you are doing research on some type of combinatorial structure definitely check with combstruct first.

My purpose in this message is to advise you of the existence of this package and encourage you to use it in your teaching and research. With this in mind I present five applications of the combstruct package. These are very basic efforts that admit improvement that can perhaps serve as an incentive to deploy combstruct nonetheless. Here they are:

I hope you enjoy reading these and perhaps you might want to feature combstruct as well, which presented the first complete implementation in a computer algebra system of the symbolic method, sometimes called the folklore theorem of combinatorial enumeration, when it initially appeared.

Best regards,

Marko Riedel.


Partial rectification for the Physics:-Simplify and Physics:-Library:-SortProducts procedures dealing with Fermi annihilation/creation operators

This post will be useful for physicists dealing with Fermi annihilation/creation operators. Physics Package provides plenty of powerful tools for quantum operators handling, however some of them often fail to render correct result.  In particular incorrect behaviour with respect to Fermi annihilation/creation operators is observed for routines Simplify and SortProducts.  In this post I present my procedures S*implifyFermionicOperators and SortProductsFermi which partially solve these issues.

Problems with Physics Package routines



Short explanation of custom routines SimplifyFermionicOperators and SortProductsFermi



"Details for SimplifyFermionicOperators(z,prefix)"



"Details for SortProductsFermi(x,L,prefix)"



Weak points



Final notes




Download FermiCreationAnnihilation.mw

I would like to announce a new unofficial record computation of the MRB constant that was finished on Sun 21 Sep 2014 18:35:06.

I really would like to see someone beat it with Maple!

It took 1 month 27 days 2 hours 45 minutes 15 seconds. I computed 3,014,991 digits of the MRB constant, (confirming my previous 2,00,000 or more digit computation was actually accurate to 2,009,993 digits), with Mathematica 10.0. I Used my version of Richard Crandall's code:



____________________________________________________________________________

(*Fastest (at MRB's end) as of 25 Jul 2014.*)

DateString[]

prec = 3000000;(*Number of required decimals.*)ClearSystemCache[];

T0 = SessionTime[];

expM[pre_] :=

  Module[{a, d, s, k, bb, c, n, end, iprec, xvals, x, pc, cores = 12,

    tsize = 2^7, chunksize, start = 1, ll, ctab,

    pr = Floor[1.005 pre]}, chunksize = cores*tsize;

   n = Floor[1.32 pr];

   end = Ceiling[n/chunksize];

   Print["Iterations required: ", n];

   Print["end ", end];

   Print[end*chunksize]; d = ChebyshevT[n, 3];

   {b, c, s} = {SetPrecision[-1, 1.1*n], -d, 0};

   iprec = Ceiling[pr/27];

   Do[xvals = Flatten[ParallelTable[Table[ll = start + j*tsize + l;

        x = N[E^(Log[ll]/(ll)), iprec];

        pc = iprec;

        While[pc < pr, pc = Min[3 pc, pr];

         x = SetPrecision[x, pc];

         y = x^ll - ll;

         x = x (1 - 2 y/((ll + 1) y + 2 ll ll));];(*N[Exp[Log[ll]/ll],

        pr]*)x, {l, 0, tsize - 1}], {j, 0, cores - 1},

       Method -> "EvaluationsPerKernel" -> 4]];

    ctab = ParallelTable[Table[c = b - c;

       ll = start + l - 2;

       b *= 2 (ll + n) (ll - n)/((ll + 1) (2 ll + 1));

       c, {l, chunksize}], Method -> "EvaluationsPerKernel" -> 2];

    s += ctab.(xvals - 1);

    start += chunksize;

    Print["done iter ", k*chunksize, " ", SessionTime[] - T0];, {k, 0,

      end - 1}];

   N[-s/d, pr]];

t2 = Timing[MRBtest2 = expM[prec];]; DateString[]

Print[MRBtest2]

MRBtest2 - MRBtest2M

_________________________________________________________________________.



I used a six core Intel(R) Core(TM) i7-3930K CPU @ 3.20 GHz 3.20 GHz with 64 GB of RAM of which only 16 GB was used.

t2 From the computation was {1.961004112059*10^6, Null}.







Greetings to all.

As some of you may remember I have posted several announcements concerning Power Group Enumeration and the Polya Enumeration Theorem this past year, e.g. at this MaplePrimes link: Power Group Enumeration.

I have continued to work in this field and for those of you who have followed the earlier threads I would like to present some links to my more recent work using the Burnside lemma. Of course all of these are programmed in Maple and include the Maple code and it is with the demonstration of Maple's group theory capabilities in mind that I present them to you (math.stackexchange links).

The third and fourth to last link in particular include advanced Maple code.

The second entry is new as of October 30 2015.

With my best wishes for happy group theory computing with Maple,

Regards,

Marko Riedel

I see two recent items on the web about Mathematica and the rosettacode.org site. One was a Wolfram Inc. corporate blog post, and the other a post on Wolfram's relatively new community site.

There are many items on the page of tasks still without a submitted Maple implementation. It would be nice to see interesting implementations of some remaining tasks, as contributions from the Maple user base. The tasks remaining are of very mixed difficulty levels.

To date there are only 132 entries on the page for Maple implementations of that site's programming tasks. (Of these about 40 were submitted by one member while about 80 were submitted by another member.)

acer

I think we all know the routine. We walk to a large classroom, we sit down for a test, we receive a large stack of questions stapled together and then we fill in tiny bubbles on a separate sheet that is automatically graded by a scanning machine. We’ve all been there. I was thinking recently about how far the humble multiple choice question has come over the last few years with the advent of systems like Maple T.A., and so I did a little research.

Multiple choice questions were first widely-distributed during World War I to test the intelligence of recruits in the United States of America. The army desired a more efficient way of testing as using written and oral evaluations was very time consuming. Dr. Robert Yerkes, the psychologist who convinced the army to try a multiple choice test, wanted to convince people that psychiatry could be a scientific study and not just philosophical. A few years later, SATs began including multiple choice questions. Since then, educational institutions have adopted multiple choice questions as a permanent tool for many different types of assessments.

One of the biggest advances in the use of multiple choice questions was the birth of automatic grading through the use of machine-readable papers. These grew in popularity during the mid-70s as teachers and instructors saved time by not having to grade answer sheets manually.

Until recently, there has not been much advancement in this area.  It’s true, Maple T.A. can do so much more than just multiple choice questions, so this style of question is less important in large-scale testing than it used to be. But multiple choice questions still have their place in an automated testing system, where uses include leveraging older content, easily detecting patterns of misunderstanding, requiring students to choose from different images, and minimizing student interaction with the system. Luckily, Maple T.A. takes even the humble multiple choice questions to the next level. Now you might be thinking, how is that even possible given the basic structure of multiple choice questions? What could possibly be done to enhance them?

Well, for starters, in Maple T.A., you can permute the answers. This means you have the option to change the order of the choices for each student. This is also possible with machine-readable papers, but this does require multiple solution sets for a teacher or instructor to keep track of. With Maple T.A., everything is done for you. For example, if you have a multiple choice question in Maple T.A. with 5 answer choices, there are 120 different possible answer orders that students can be presented with. You don’t have to keep track of extra solution sets or note which test version each student is receiving. Maple T.A. takes care of it all.

Maple T.A. allows you to create Algorithmic questions - multiple choice questions in which you can vary different values in your question. And you aren’t limited to selecting values from a specific range, either. For example, you can select a random integer from a pre-defined list, a random number that satisfies a mathematical condition, such as ‘divisible by 3’ or ‘prime’, or even a random polynomial or matrix with specific characteristics. It allows an instructor to create a single question template, but have tens, hundreds, or even thousands of possible question outcomes based on the randomly selected values for the algorithmic variables. The algorithmic variables not only apply to the question being asked by a student, but also the choices they see in a multiple choice question.

You can even create a question where every student gets the same fixed list of choices, but the question varies to ensure that the correct response changes.  That’s going to confuse some students who are doing a little more “collaboration” than is appropriate!

Some of the other advantages of using Maple T.A. for multiple choice are also common to all Maple T.A. question types. For example, you can provide instant, customized feedback to your students. If a student gets a multiple choice question correct, you can provide feedback showing the solution (who is to say the student didn’t guess and get this question correct?) If a student gets a multiple choice question incorrect, you can provide targeted feedback that depends on which response they chose. This allows you to customize exactly what a student sees in regards to feedback without having to write it out by hand each time.

And of course, like in other Maple T.A. questions, multiple choice questions can include mathematical expressions, plots, images, audio clips, videos, and more – in the questions and in the responses.

Finally, let’s not forget, in an online testing environment, there is no panic when you realized you accidently skipped line 2 while filling out your card, no risk of paper cuts, and no worrying about what kind of pencil to use!

References:

http://www.edutopia.org/blog/dark-history-of-multiple-choice-ainissa-ramirez

http://xkcd.com/499/

http://io9.com/5908833/the-birth-of-scantrons-the-bane-of-standardized-testing

Greetings to all.

I would like to share a brief observation concerning my experiences with the Euler-Maclaurin summation routine in Maple 17 (X86 64 LINUX). The following Math StackExchange Link shows how to compute a certain Euler-MacLaurin type asymptotic expansion using highly unorthodox divergent series summation techniques. The result that was obtained matches the output from eulermac which is definitely good to know. What follows is the output from said routine.

> eulermac(1/(1+k/n),k=0..n,18);
     1       929569        3202291        691                O(1)
O(- ---) - ----------- + ----------- - --------- + 1/1048576 ----
     19             15            17          11              19
    n      2097152 n     1048576 n     32768 n               n

                                           n
                                          /
        174611      5461        31       |      1           17        1
     - -------- + --------- + ------- +  |   ------- dk - ------- + ------
             19          13         9    |   1 + k/n            7        5
       6600 n     65536 n     4096 n    /                 4096 n    256 n
                                          0

         1       1
     - ------ + ---- + 3/4
            3   16 n
       128 n

While I realize that this is good enough for most purposes I have two minor issues.

  • One could certainly evaluate the integral without leaving it to the user to force evaluation with the AllSolutions option. One can and should make use of what is known about n and k. In particular one can check whether there are singularities on the integration path because we know the range of k/n.
  • Why are there two order terms for the order of the remainder term? There should be at most one and a coefficient times an O(1) term makes little sense as the coefficient would be absorbed.

You might want to fix these so that the output looks a bit more professional which does enter into play when potential future users decide on what CAS to commit to. Other than that it is a very useful routine even for certain harmonic sum computations where one can use Euler-Maclaurin to verify results.

Best regards,

Marko Riedel

Greetings to all.

It is a new year (for some time now) and I am writing to indicate that the mathematical adventures with cycle index computations and Maple continue!

Here are the previous installments:

My purpose this time is to alert readers who might be interested to a new cycle index computation that is neither an application of the classical form of the Polya Enumeration Theorem (PET) nor of Power Group Enumeration. The former counts objects being distributed into slots with a group acting on the slots and the latter objects going into slots with a second group which permutes the objects in addition to the slots being permuted. What I am about to present treats a third possible case: when the slot permutation group and the object permutation group are one and the same and act simultaneously (not exactly the same but induced by the action of a single group).

This requires quite radical proceedings in the etymological sense of the word, which is to go back to the roots of a problem. It seems that after working with the PET sooner or later one is confronted with enumeration problems that demand the original unmitigated power of Burnside's lemma, sometimes called the lemma that is not Burnside's. This is the case with the following problem. Suppose you have an N-by-N matrix whose entries are values from 1 to N, with all assignments allowed and the symmetric group on N elements acts on the row and column indices permuting rows and columns as well as the entries simultaneously. We ask how many such matrices there are taking these double symmetries into account. This also counts the number of closed binary operations on a set of N elemnents and there is a discussion as well as the Maple code (quite simple in my opinion and no more than a few lines) that solves this problem at the following Math Stackexchange link, which uses Lovasz Formula for the cycle index of the symmetric group which some readers may remember.

In continuing the saga of Polya and Burnside exploration I have often reflected on how best to encapsulate these techniques in a Maple package. With this latest installment it would appear that a command to do Burnside enumeration probably ought to be part of such a package.

Best regards,

Marko Riedel

Event?

January 2014: Pages of oldest Russian Maple Application Center have been opened 10000000 times.

http://webmath.exponenta.ru/

5 6 7 8 9 10 11 Last Page 7 of 21
