f := (z, t) -> ln(t)^2/((t^2+1)*(t-z));

int(f(z, t), t = 0 .. infinity) assuming Im(z) > 0;
       int(ln(t)^2/((t^2+1)*(t-z)), t = 0 .. infinity)

int(f(a + I*b, t), t = 0 .. infinity) assuming a::real, b > 0; # 0*infinity
       -sqrt(a^2+b^2-2*b+1)*signum(I*arctan(b, a)-I*arctan(-b, -a)-I*Pi)*
       infinity/((I*b-I+a)*(I*b+I+a))

int(f(z, t), t = 0 .. infinity) assuming Re(z) > 0, Im(z) > 0;
       int(ln(t)^2/((t^2+1)*(t-z)), t = 0 .. infinity)

int(f(a + I*b, t), t = 0 .. infinity) assuming a > 0, b > 0;
      -((3*I)*Pi^3*b+3*Pi^3*a-(16*I)*Pi^2*arctan(b/a)-(6*I)*Pi*ln(a^2+b^2)^2+(24*I)*
      Pi*arctan(b/a)^2+(6*I)*ln(a^2+b^2)^2*arctan(b/a)-(8*I)*arctan(b/a)^3-8*Pi^2*
      ln(a^2+b^2)+24*Pi*ln(a^2+b^2)*arctan(b/a)+ln(a^2+b^2)^3-12*ln(a^2+b^2)*
      arctan(b/a)^2)/(24*(-b^2+(2*I)*a*b+a^2+1))

So it looks like the first three can be made to work as well (and the result in terms of z will be much neater).

the Eigenvalues are showing with I and am not expecting a complex eigenvalues so what is that I stand for? Can you please help? Thank You

Hi

I've got this list:

L:=[[TC,DB], [], [TD,JK], [IW,CM], [], [KJ,DJ]]

What command to remove the 'null sets', leaving :=[[TC,DB],[TD,JK], [IW,CM], [KJ,DJ]]

this doesn't work:

remove(has, L, 0)

I've compiled a program with Maple 18. unfortunately it gives me the message "Large sortie de plus de 1000000 noeuds". If any one have any idea to resolve this problem. Thanks you very mutch for your support.

With Startup Code Editor opened, save and close the parent worksheet. Any unsaved changes in the Code Editor are lost.

A project that I have been working on is adding some functionality for Cluster Analysis to Maple (a small part of a much bigger project to increase Maple’s toolkit for exploratory data mining and data analysis). The launch of the MapleCloud package manager gave me a way to share my code for the project as it evolves, providing others with some useful new tools and hopefully gathering feedback (and collaborators) along the way.

At this point, there aren’t a lot of commands in the ClusterAnalysis package, but I have already hit upon several interesting applications. For example, while working on a command for plotting clusters of points, one problem I encountered was how to draw the minimal volume enclosing ellipsoid around a group (or cluster) of points. After doing some research, I stumbled upon Khachiyan’s Algorithm, which related to solving linear programming problems with rational data. The math behind this is definitely interesting, but I’m not going to spend any time on it here. For further reading, you can explore the following:

• Ellipsoid Method: https://en.wikipedia.org/wiki/Ellipsoid_method
• The Ellipsoid (Kachiyan) Method: https://web.stanford.edu/class/msande310/ellip.pdf
• A note on Approximate Minimum Volume Enclosing Ellipsoid of Ellipsoids: http://compgeom.com/~piyush/papers/emve.pdf

Khachiyan’s Algorithm had previously been applied in some other languages, but to the best of my knowledge, did not have any Maple implementations. As such, the following code is an implementation of Khachiyan’s Algorithm in 2-D, which could be extended to N-dimensional space rather easily.

This routine accepts an Nx2 dataset and outputs either a plot of the minimum volume enclosing ellipsoid (MVEE) or a list of results as described in the details for the ‘output’ option below.

MVEE( X :: DataSet, optional arguments, additional arguments passed to the plotting command );

The optional arguments are as follows:

• tolerance : realcons;  specifies the convergence criterion
• maxiterations : posint; specifies the maximum number of iterations
• output : {identical(data,plot),list(identical(data,plot))}; specifies the output. If output includes plot, then a plot of the enclosing ellipsoid is returned. If output includes data, then the return includes is a list containing the matrix A, which defines the ellipsoid, the center of the ellipse, and the eigenvalues and eigenvectors that can be used to find the semi-axis coordinates and the angle of rotation, alpha, for the ellipse.
• filled : truefalse; specifies if the returned plot should be filled or not

Code:

You can run this as follows:

As it stands, this is not an export from the “work in progress” ClusterAnalysis package – it’s actually just a local procedure used by the ClusterPlot command. However, it seemed like an interesting enough application that it deserved its own post (and potentially even some consideration for inclusion in some future more geometry-specific package). Here’s an example of how this routine is used from ClusterAnalysis:

The source code for this is stored on GitHub, here:

https://github.com/dskoog/Maple-ClusterAnalysis/blob/master/src/MVEE.mm

Comments and suggestions are welcomed.

If you don’t have a copy of the ClusterAnalysis package, you can install it from the MapleCloud window, or by running:

I tried to solve 4 simultaneous equations but the result is an empty matrix.

Is that because there is no solution or did I make something wrong?

You can download the file by using the link below.

SimEquations.mw

hi

I have a matrix (for example a 6*6 matrix) and I want to add a row and a column between row and column of number 3 and 4. it means that finally, we have a 7*7 matrix.

tnx

The documentation says that Subgroup(c) returns the subgroup of the coset c.

Also, the display of Elements(lc) is garbled in Maple as well, not just in the image.

These worksheets provide the volume calculations  of a small causal diamond near the tip of the past light cone, using dimensional analysis and particular test metrics.

I recommend them for anyone working in causet theory on the problem of finding higher order corrections.

2D.mw

4D.mw

4Dflat.mw

I want to highlight the intersection between 2 graphs; pp(m,a) and the plane m=-0.2

PP := .8707945038*exp(-50.00000000*(m-0.842e-1)^2+(2.745342070*(m-0.842e-1))*(a-2.3722)-.1046792095*(a-2.3722)^2)

How can I do that?

Thank you

Hello every body

I have a plot that contains two curve. I need to chracterize the curves with `min(D_{T})` and `max(D_{E})`. Is it possible to write legend of plot such that when include it in latex file,  T and E be presented in indices?

With this app you will be able to interpret the curvatures generated by two position vectors, either in the plane or in space. Just enter the position vectors and drag the slider to calculate the curvature at different times and you will of course be able to observe its respective graph. At first I show you how it is developed using the natural syntax of Maple and then optimize our
 app with the use of buttons. App made in Maple for engineering students. In spanish.

Plot_of_Curvature.mw

Videotutorial:

https://www.youtube.com/watch?v=SbXFgr_5JDE

Lenin Araujo Castillo

Ambassador of Maple

i used this  commend to plot three equation and it actually work .my question her how to show any point cordinates just i pointed on it ? could i do it by maple or what ?
help please
implicitplot3d({f[1], f[2], f[3]}, Q[h] = 0 .. 100, S[h] = 0 .. 100, R[h] = 0 .. 100);

when i evaluate this summation if Q[h],S[h],R[h] are big floating numbers it take along time how i decrease this time
P := simplify(sum(sum((t+1)*Q[h]^2*(1-Q[h])^(t+T)/(t+1+(R[h]/S[h])^sigma*(T+1)), t = 0 .. infinity), T = 0 .. infinity))
