Would it be possible to give a numeric value for the parameter g?

You mentioned wanting to do this with a seq command. This is possible, even in one line. This method is even significantly faster than my previous answer. But this method can produce a tremendous amount of garbage (memory) to be collected, because it generates the powerset of T. So, WARNING: Do not use this procedure if is larger than about 25 sets.

UnionClosure:= (T::set(set))->
   {seq}(`union`(X[]), X= combinat:-powerset(T minus {{}, `union`(T[])})):


UnionClosure({{1}, {1,2}, {3}});
           {{}, {1}, {3}, {1, 2}, {1, 3}, {1, 2, 3}}

Both of my UnionClosure procedures are many, many times more efficient than the previous answers in this thread.

You mentioned wanting to do this with a seq command. This is possible, even in one line. This method is even significantly faster than my previous answer. But this method can produce a tremendous amount of garbage (memory) to be collected, because it generates the powerset of T. So, WARNING: Do not use this procedure if is larger than about 25 sets.

UnionClosure:= (T::set(set))->
   {seq}(`union`(X[]), X= combinat:-powerset(T minus {{}, `union`(T[])})):


UnionClosure({{1}, {1,2}, {3}});
           {{}, {1}, {3}, {1, 2}, {1, 3}, {1, 2, 3}}

Both of my UnionClosure procedures are many, many times more efficient than the previous answers in this thread.

Throughout this Comment, let |V| represent the number of vertices in a (finite simple) graph, let |E| represent the number of edges, and let P(C) represent the probability that a random graph (randomly selected by the "G(n, p)" model of Erdos and Renyi) with those parameters is connected. As Markiyan's title of the Post suggests, the distribution of P(C) as a function of |E| for given |V| is an all-or-nothing phenomenon. Or, in the language of the Wikipedia page that was referenced, it is a "sharp threshold" phenomenon, with the threshold being |E| = ln(|V|)*(|V|-1)/2. (This corresponds to n = |V|, p = ln(|V|) / |V| in the G(n, p) model.) In other words, for |E| > ln(|V|)*(|V|-1)/2, limit(P(C), |V|= infinity) = 1; and for |E| < ln(|V|)*(|V|-1)/2, limit(P(C), |V|= infinity) = 0. Or in the language of Random Graph Theory, in the former case "almost every" graph in G(n, p) is connected; while in the latter case "almost every" graph is disconnected.

In the plot, I would've liked to see the numbers of vertices and edges on the axes. In the code below I regenerate the plot with this information. Otherwise, the plot uses the same parameters as the original. I have also plotted the threshold function ln(|V|)*(|V|-1)/2 on the same plot. You can see that the plot models the threshold phenomenon nearly perfectly.



restart;

Ntrials:= 100:
Emin:= 60:  Emax:= 360:  Eskip:= 30:
Vmin:= 30:  Vmax:= 360:  Vskip:= 10:

Pr:= Array(
     1 .. 1 + iquo(Vmax-Vmin, Vskip),
     1 .. 1 + iquo(Emax-Emin, Eskip),
     1..3,
     datatype= float[8]
):

for E from Emin by Eskip to Emax do
     for V from Vmin by Vskip to Vmax do
          ct:= 0;
          if E >= V-1 then  #threshold of possibility of connectedness
               to Ntrials do
                    if GraphTheory:-IsConnected(
                         GraphTheory:-RandomGraphs:-RandomGraph(V,E)
                    ) then
                         ct:= ct+1
                    end if
               end do
          end if;
          Pr[1 + (V-Vmin)/Vskip, 1 + (E-Emin)/Eskip, ..]:=

               < V, E, ct/Ntrials >
     end do
end do:

P1:= plots:-surfdata(Pr, transparency= .4):

P2:= plots:-spacecurve([n, ln(n)*(n-1)/2, 0], n= Vmin..Vmax,
     thickness= 4, color= red
):

plots:-display([P1,P2], view= [Vmin..Vmax, Emin..Emax, 0..1],
     labels= ['V','E','P(C)']
);





Download RandomGraphs.mw

@J4James Good question. Ordinarily, I wouldn't rely on "magic numbers" such as the position numbers 3 or 4. And there's no need to if you use eval. Let's take a look at the structure of the "listprocedure":

PDE:={diff(u(x,t),t)=w(x,t), diff(u(x,t),x)=-w(x,t)}:
IBC:= {u(x,0)=sin(2*Pi*x),u(0,t)=-sin(2*Pi*t)}:
pds:= pdsolve(PDE, IBC, numeric, time=t, range=0..1):

LP:= pds:-value(output=listprocedure);
  LP:= [x = proc()  ...  end proc, t = proc()  ...  end proc,

    u(x, t) = proc()  ...  end proc, w(x, t) = proc()  ...  end proc]

So, it's a list of assignment equations. So we apply eval:

W:= eval(w(x,t), LP);
W:= proc()  ...  end proc

Is that clear?

@J4James Good question. Ordinarily, I wouldn't rely on "magic numbers" such as the position numbers 3 or 4. And there's no need to if you use eval. Let's take a look at the structure of the "listprocedure":

PDE:={diff(u(x,t),t)=w(x,t), diff(u(x,t),x)=-w(x,t)}:
IBC:= {u(x,0)=sin(2*Pi*x),u(0,t)=-sin(2*Pi*t)}:
pds:= pdsolve(PDE, IBC, numeric, time=t, range=0..1):

LP:= pds:-value(output=listprocedure);
  LP:= [x = proc()  ...  end proc, t = proc()  ...  end proc,

    u(x, t) = proc()  ...  end proc, w(x, t) = proc()  ...  end proc]

So, it's a list of assignment equations. So we apply eval:

W:= eval(w(x,t), LP);
W:= proc()  ...  end proc

Is that clear?

I just want to state more clearly what taylor and numapprox:-laurent do, because it seems a bit strange (that they don't do much). Neither of these commands will ever return a series which is different from the one returned by the basic command series. They take the series returned by series, decide whether that series is a Taylor or Laurent series, and return either that series unchanged or an error message. So it is essentially a type checking of the output of series. This might be useful when used in a program, but it doesn't seem worthwhile in "desktop calculator mode" since it is usually obvious to the "naked eye" whether a series is Laurent, Taylor, or neither.

I just want to state more clearly what taylor and numapprox:-laurent do, because it seems a bit strange (that they don't do much). Neither of these commands will ever return a series which is different from the one returned by the basic command series. They take the series returned by series, decide whether that series is a Taylor or Laurent series, and return either that series unchanged or an error message. So it is essentially a type checking of the output of series. This might be useful when used in a program, but it doesn't seem worthwhile in "desktop calculator mode" since it is usually obvious to the "naked eye" whether a series is Laurent, Taylor, or neither.

Extending that technique, we get the following options:

ex:= 1/sqrt(3);
                            1  (1/2)
                            - 3
                            3

subs(3= `3`, 1/3= 1/`3`, ex);
                               1
                             ------
                              (1/2)
                             3

subs(3= ``(3), 1/3= 1/``(3), ex);
                               1
                            --------
                               (1/2)
                            (3)

which all appear with the standard square root sign instead of a fractional exponent in the GUI.

Extending that technique, we get the following options:

ex:= 1/sqrt(3);
                            1  (1/2)
                            - 3
                            3

subs(3= `3`, 1/3= 1/`3`, ex);
                               1
                             ------
                              (1/2)
                             3

subs(3= ``(3), 1/3= 1/``(3), ex);
                               1
                            --------
                               (1/2)
                            (3)

which all appear with the standard square root sign instead of a fractional exponent in the GUI.

@rachie90 The situation which is described in the paragraph following the one containing equation (2.2) in Tsuchiya's paper is exactly what is happening in your case: G'/G'' is going to 0/0 (where I'm abusing the derivative notation a bit, but you know what I mean). G'' is going to 0 a little faster, so this is manifested in the floating-point arithmetic as the values getting extremely large.

So, I guess that it's time to try equation (2.3). I think (although I'm far from sure) that this is equivalent to handling r and z together, so we're just dealing with gradients and Hessians of functions of two variables.

I guess that you saw that Tsuchiya does the catenoid problem later in the paper.

@rlopez  Thanks, it works. A plot shows clearly that -W is the correct derivative. Either

plot(-W(0,t), t= 0..1);

or

pds:-plot(-w(x,t), x=0, t= 0..1);

gives the plot of diff(u(x,t), x) for x=0.

With pdsolve, there seems to be a very subtle difference between what works in this context and what is "too far from a standard form".

@rlopez  Thanks, it works. A plot shows clearly that -W is the correct derivative. Either

plot(-W(0,t), t= 0..1);

or

pds:-plot(-w(x,t), x=0, t= 0..1);

gives the plot of diff(u(x,t), x) for x=0.

With pdsolve, there seems to be a very subtle difference between what works in this context and what is "too far from a standard form".

Thank you for your Answer. I was not familiar with the method of extracting the solution procedures. To answer the question that you pose rhetorically in the title of your Answer, there are two reasons:

  1. It just seems more natural to me to work with the plots, because I am well acquainted with the internal structure of plots and rtables, but not at all well acquainted with the internal structure of the modules returned by pdsolve. Certainly this is just a matter of taste.
  2. It hardly matters for this small example, but the plot method seems to use substantially less cputime (about 1/3 the time in this example). I haven't looked into why this is, but my guess is that the plots allow for more processing by evalhf in a "batch mode", i.e., fewer total calls to evalhf with each doing more work.

Robert Lopez wrote:

To get the values of the highest-ordered derivative, ... trick the system into thinking ... that the derivative is actually one of the system's dependent variables.

Could you give an example of this with pdsolve(..., numeric)? I am familiar with how to do this with dsolve(..., numeric), but when I try with pdsolve, I get an error message about the system being "too far from a standard form".

PDE:= {diff(u(x,t),t) = -diff(u(x,t),x), diff(u(x,t),x)= w(x,t)}:
IBC:= {u(x,0)=sin(2*Pi*x),u(0,t)=-sin(2*Pi*t)}:
pds:= pdsolve(PDE, IBC, numeric, time=t, range=0..1);
Error, (in pdsolve/numeric/par_hyp) input system is too far from a 'standard' form (see ?pdsolve,numeric for more detail)

Thank you for your Answer. I was not familiar with the method of extracting the solution procedures. To answer the question that you pose rhetorically in the title of your Answer, there are two reasons:

  1. It just seems more natural to me to work with the plots, because I am well acquainted with the internal structure of plots and rtables, but not at all well acquainted with the internal structure of the modules returned by pdsolve. Certainly this is just a matter of taste.
  2. It hardly matters for this small example, but the plot method seems to use substantially less cputime (about 1/3 the time in this example). I haven't looked into why this is, but my guess is that the plots allow for more processing by evalhf in a "batch mode", i.e., fewer total calls to evalhf with each doing more work.

Robert Lopez wrote:

To get the values of the highest-ordered derivative, ... trick the system into thinking ... that the derivative is actually one of the system's dependent variables.

Could you give an example of this with pdsolve(..., numeric)? I am familiar with how to do this with dsolve(..., numeric), but when I try with pdsolve, I get an error message about the system being "too far from a standard form".

PDE:= {diff(u(x,t),t) = -diff(u(x,t),x), diff(u(x,t),x)= w(x,t)}:
IBC:= {u(x,0)=sin(2*Pi*x),u(0,t)=-sin(2*Pi*t)}:
pds:= pdsolve(PDE, IBC, numeric, time=t, range=0..1);
Error, (in pdsolve/numeric/par_hyp) input system is too far from a 'standard' form (see ?pdsolve,numeric for more detail)
