These are questions asked by minhthien2016

I want to draw circle passing thought three points S, A, B on the sphere by using tikz-3dplot-circleofsphere, its document at here https://github.com/matthias-wolff/tikz-3dplot-circleofsphere/blob/master/tikz-3dplot-circleofsphere.pdf The command to draw is
\tdplotCsDrawCircle[style]{r}{alpha}{beta}{epsilon}

With Maple, I can find the coordinates of center and radius of circle. I tried


restart;
with(geom3d):
 a := 3:
 b := 4:
 h := 5:
 point(A, 0, 0, 0):
 point(B, a, 0, 0):
 point(C, a, b, 0):
 point(DD, 0, b, 0):
 point(S, 0, 0, h):
 sphere(s, [A, B, C, S], 'centername' = m); detail(s); plane(p, [S, A, B], [x, y, z]); coordinates(projection(H, m, p));
R := distance(H, S)

But, I can't to find the angles alpha, beta, epsilon to draw this circle. How can I find  the angles alpha, beta, epsilon?

In this question at here https://tex.stackexchange.com/questions/503745/how-can-i-get-correct-the-point-a-and-b-automatically-in-this-picture/503838?noredirect=1#comment1272706_503838
The points A and B lie on the circle is intersection of the sphere x^2 + y^2 + (z-3)^2 = 25 and the plane z = 0.
How can I find coordinates of the points A and B by Maple?



Let be given a cylinder with radius of the base circle is equal to 3 and the altitude of the cylinder is equal to 2. How can I draw square ABCD so that A, B and C, D lie on two base circles. How can I get one option of all vetices A, B, C, D ?

I calculate volume of tetrahedron SABC by this way. Now, I want to find one option  of coordinates of all vertices of this tetrahedron. How can I get the coordinates of the points S, A, B, C so that coordinates  center of circumcircle of the triangle ABC is (0,0,0)?



restart:
SA := 3:
SB := 5:
SC := 7:
AB := 3:
BC := 4:
AC := 5:
V := (1/12)*sqrt(SA^2*BC^2*(AB^2+AC^2-BC^2-SA^2+SB^2+SC^2)+SB^2*AC^2*(AB^2-AC^2+BC^2+SA^2-SB^2+SC^2)+SC^2*AB^2*(-AB^2+AC^2+BC^2+SA^2+SB^2-SC^2)-SA^2*AB^2*SB^2-SB^2*BC^2*SC^2-SA^2*AC^2*SC^2-AB^2*BC^2*AC^2);

From here https://www.mapleprimes.com/questions/227573-How-To-Get-Coordinates-Of-Triangle-ABC
I find coordinates of the point A, B, C. Now I tried


with(geom3d):
point(A, -3/2, -2, 0):
point(B, 3/2, -2, 0):
point(C, -3/2, 2, 0):
point(S, x, y, z):
solve([distance(S, A) = 3, distance(S, B) = 5, distance(S, C) = 7], [x, y, z], explicit);
with(geom3d):
point(A, -3/2, -2, 0):
point(B, 3/2, -2, 0):
point(C, -3/2, 2, 0):
point(S, x, y, z):
solve([distance(S, A) = 5, distance(S, B) = 3, distance(S, C) = 7], [x, y, z], explicit);

Use the above code, I obtain the result.

How to get correct result this equation
restart; with(Student:-MultivariateCalculus);
A := [0, 0, 0];
B := [c, 0, 0];
S := [x, 0, z];
solve([Distance(S, A) = a, Distance(S, B) = b], [x, z]) assuming and(a > 0, b > 0, c > 0);
